Clas Ohlson WTD1366600A Manual

Battery pack, 6600 mAh
Art.no 38-4844 Model WTD1366600A
Please read the entire instruction manual before using the product
and save it for future reference. We reserve the right for any
errors in text or images and any necessary changes made to
technical data. If you have any questions regarding technical
problems please contact our Customer Services.
Safety
Follow the instructions carefully as incorrect use of the product's
lithium polymer batteries can lead to overheating, smoke or
combustion.
• Never subject the battery pack to direct sunlight,
high temperatures, dusty environments, heavy vibrations,
impacts, moisture or damp.
• If the battery pack has been damaged in any way it
must not be used, but should disposed of according to
applicable regulations.
• The battery pack should not be taken apart or modified.
• The battery pack must not be subjected to knocks or blows.
• Make sure the battery pack is stored out of the reach of children.
• The battery pack may only be charged via its USB connection.
Product description
Powerful 6600 mAh battery pack for charging your iPhone,
iPod, iPad, smartphone or USB devices. Once your regular
battery becomes flat the battery pack kicks in to drive and
charges your device at the same time. 1 × USB port (1 A) and
1 × USB port (2.1 A), Micro USB port and power indicator lamp.
Charges from your computer's USB port or using the included
Micro USB cable.
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Buttons and functions
5
4
1 2 3
1. USB port 2.1 A 4. [On/off]
2. USB port 1 A 5. Battery charge status indicator
3. Micro USB port 6. Micro USB cable
Operation
Charging the battery pack
The battery pack's built-in battery can be charged via a
USB port using external power sources such as computers or
USB chargers. If the battery pack is completely discharged,
the charging process could take 13–14 hours.
1. Connect one end of the Micro USB cable to the battery
pack's Micro USB port, and the other end to the external
power source's USB port.
2. The battery charge status indicator shows when the battery
is being charged. The LEDs light up sequentially; when all
four LEDs are lit, the battery is fully charged.
Charging devices from the battery pack
1. Connect the external device to one of the battery pack's
USB ports.
2. Begin charging the device by pressing the [On/off] button.
3. The battery pack's charge status indicator will come on
for 5 seconds to indicate that it has started charging
the device. Check the charge status of your external device
on the device directly. The battery charge status indicator
does NOT light up during the charging process.
4. When the external device has been charged, disconnect
the USB cable.
Battery charge status indicator
Check charge levels in the battery pack by pressing [On/off]:
Flashing indicator = <20%
1 LED lights up = 20–40%
2 LEDs light up = 40–60%
6
3 LEDs light up = 60–80%
4 LEDs light up = 80–100%

Care and maintenance

Charge the battery pack every third month when it is not in use.
Clean the product by wiping it with a soft, dry cloth. Never use
abrasive cleaning agents or solvents.
Disposal
This product should be disposed of in accordance with local
regulations. If you are unsure how to proceed, contact your
local authority.

Specifications

Size 11 × 8.5 × 1.5 cm
Capacity 6600 mAh
Charging battery pack 5 V DC, 1 A max
Output port 1 to
external device 5 V DC, 1 A
Output port 2 to
external device 5 V DC, 2.1 A
Mobile phones, iPhones, iPods,
Port 1
other digital devices
Port 2 iPads, iPhones
