Clas Ohlson HTD22110A Instruction Manual

Battery Pack
Art.no 38-7062 Model HTD22110A
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.

Safety

• Never subject the product to direct sunlight, high
temperatures, dusty environments or heavy vibrations.
• Do not use the product if it or its mains lead/charger lead is
damaged in any way.
• The product must not be taken apart or modified.
• Do not use the product in an area where flammable liquids
or gases are used or stored.
• Never expose the product to impacts, shocks, rain, liquids
or moisture.
• Make sure that the product is stored out of the reach of children.
• The product may only be charged via a USB port.

Buttons and functions

1. USB port (2.4 A) for
1 2
charging an iPad/
phone
2. Micro-USB port
for charging
the battery pack
3. USB port (1 A)
for charging
a mobile phone
4. LED battery status
indicator
5. On/off, battery
status
GREAT BRITAIN • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk
Charging the battery pack
1. Connect the included charger lead to the Micro-USB port
(2) on the battery pack and to a computer or other USB
charger.
2. When all the LEDs of the battery status indicator are
lit, the battery pack is fully charged. If fully discharged,
the battery pack will take 8½ hours to charge.

Charging external devices

1. Connect the included charger cable (or the charger cable of
the device to be charged) to one of the USB ports (1 or 3)
and to the external device.
2. Press the battery status check button (4) to start
the charging. The LED indicators light up for a few seconds
to show the battery status of the battery pack and then go
out again.
3. To check the battery status of the battery pack whilst
charging is in progress, press the battery status check
button again.
4. The LED indicators show the battery charge status of
the battery pack as follows:
Capacity LED 1
75–100 % Steady
glow
3 4 5
50–75 % Steady
glow
25–50 % Steady
glow
10–25 % Steady
glow
0–10 % Flashing

Care and maintenance

• Clean the battery pack using a lightly moistened cloth.
Use only mild cleaning agents, never solvents or corrosive
chemicals.
• Fully charge the battery pack every third month if it is not to
be used for a long time.
• Store the battery pack indoors, in a dry, dust-free place out
of children's reach.
LED 2 LED 3 LED 4
Steady Steady Steady
glow glow glow
Steady Steady Off
glow glow
Steady Off Off
glow
Off Off Off
Off Off Off

Responsible disposal

This symbol indicates that this product should not
be disposed of with general household waste.
This applies throughout the entire EU. In order to
prevent any harm to the environment or health
hazards caused by incorrect waste disposal,
the product must be handed in for recycling so that
the material can be disposed of in a responsible
manner. When recycling your product, take it to
your local collection facility or contact the place
of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.

Specifications

Capacity 12000 mAh
Input for charging
the battery pack 5 V DC/Max 2 A
Battery pack output 5 V/ 1 A and 5 V/ 2.4 A
Size 94 × 79 × 22 mm
Weight 270 g
Operating temperature 0–45 °C
The product can be charged/discharged up to 300 times
without loss of capacity.
