nuPro X-3000 and X-4000 X compact speakers in stereo set-ups

QUICK START

GUIDE
You can find the most recent version of the operating manual here: www.nubert.de/downloads/61/
1
Cable connections
Please connect all sources and the optional sub-
woofer to one of the two speakers of the stereo
pair.
Analogue XLR connection: Here, as an exception, each loudspeaker
is supplied with the corresponding signal separately.
At the digital Port input, you can plug in the supplied HDMI/ARC
adapter, enabling the direct connection of a TV.
Each nuPro loudspeaker is connected to the power grid using
the supplied power-cable.
Press the power switch on the back to turn on the speaker! If neces-
sary, press the power-button on the remote control to "wake up" the
speaker.
nuPro X-3000/4000 · Quick Start Guide E12 · 11/2019
1
®
E12

Advertisement

loading
Need help?

Need help?

Do you have a question about the nuPro X-4000 X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nubert nuPro X-4000 X

  • Page 1: Quick Start

    X-3000 and X-4000 X compact speakers in stereo set-ups QUICK START GUIDE You can find the most recent version of the operating manual here: www.nubert.de/downloads/61/ Cable connections Please connect all sources and the optional sub- woofer to one of the two speakers of the stereo pair.
  • Page 2 Master-slave connection The speaker you connected your sources to must The master speaker controls and passes the correct audio signal on to the second (slave-)speaker. be set as the Master speaker. In order to achieve this, the speakers must be connected to each other.
  • Page 3 Channel selection ➀ Finally, you may have to change the default channel -30dB < > coax 1 settings. If the left speaker is your Master speaker, you can skip this step. < ➁ volume < > If your Master speaker is the right speaker you need to change the settings as follows: ➀...
  • Page 4 The latter menu is identical to that on the speaker itself. nuPro X-3000/4000 · Quick Start Guide E12 · 11/2019 Screenshots: App V1.3 ® Nubert electronic GmbH · Goethestr. 69 · D-73525 Schwäbisch Gmünd · www.nubert.de · info@nubert.de · Hotline: +49 7171 92690 118, Germany 0800-6823780...
