Diverge 4 Assembly Instructions
Materials Needed:
- Diverge 4 aluminium shell
- Diverge 4 switch mount plate
- Diverge 4 back plate
- Switches
- Screws
- TRRS socket
1. Place the TRRS socket into the slot
below and solder it on.
3. Screw in the screws connecting the
switch plate with the case.
Tools Needed:
- Soldering iron
- Solder
- Phillips head screw driver
2. Place the switch plate into the case.
3. Place switches into the switch plate
make sure to orient the switches
correctly so that the LED slot points
up.
