- Page 1 User Manual PPD 3000 Touch Screen LCD Monitor Version 2.2 © Copyright Fametech Inc. (TYSSO), 2017...
-
Page 3: General Information
The information in this manual is subject to change without notice due to rapid improvement on IT technology. The users can get the most up to date information from our web site: h ttp://www.fametech.com.tw WARNING The terminal has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. -
Page 4: Trade Marks And Service Marks
TRADE MARKS AND SERVICE MARKS TYSSO is a registered trademark of FAMETECH INC. Other brand and product names are trademarks and registered trademarks and service marks of their respective owners. IMPORTANT SAFETY INFORMATION Read all these instructions carefully. Use only parts, especially power adapter, recommended by the manufacturer; unapproved ... -
Page 5: Table Of Contents
Contents General Information ....................i ABOUT THIS MANUAL ..................i WARNING ......................i WARRANTY LIMITS ....................i TRADE MARKS AND SERVICE MARKS ............... ii IMPORTANT SAFETY INFORMATION ..............ii Introduction ......................3 Unpacking ....................3 Product Overview ..................4 I/O Ports and Connectors ................6 Specifications .................... -
Page 7: Introduction
1 Introduction The PPD series POS monitors are high-quality, durable LCD touch screen that comes with a steady aluminum die-casting base and standard 75mm VESA mounting holes. The PPD series is designed with the ability to integrate with any POS peripheral devices, such as speakers, rear top mount or pole type customer display, magnetic card reader, and second monitor. -
Page 8: Product Overview
Product Overview Front View Rear View ... - Page 9 Side View Bottom View ...
-
Page 10: I/O Ports And Connectors
I/O Ports and Connectors PS/2 interface MSR cable (*optional) USB interface MSR cable (*optional) RS-232 interface MSR cable (*optional) USB interface touch cable (** touch screen only) RS-232 interface touch cable (**touch screen only) Audio cable (*optional) VGA cable * Optional accessories (MSR, external speakers and cables) are purchased separately and please contact local representative for further information. -
Page 11: Specifications
Specifications Model PPD-3000 15” TFT LCD Brightness 300 nits Resolution 1024 x 768 Pixel 5 Wire Resistive Type, Touch Screen 4/9/25-Point Calibration Tilting Angle 15 ~ 90 Degrees I/O Ports Serial RS-232 DB-9 x 2 (Optioned Touch x 1, MSR x1) USB2.0 x 1 for Touch Panel RJ 45 PS2, or USB Optioned for MSR... -
Page 12: Monitor Setting
2 Monitor Setting OSD Control Panel Button Function Power Turn on/off the monitor Auto Adjust a. Automatically optimize and adjust the screen settings. b. Exit the OSD menu. a. Increase the volume. b. Increase the value of the function selected or move to the previous function as the OSD menu is active. -
Page 13: On-Screen Display
2.2 On-Screen Display OSD Main Menu Item Description Automatically optimize and adjust the color Auto Color settings. Adjust the degree of difference between Contrast lightness and darkness. Adjust the balance between lightness and Color Brightness darkness. Color Temperature Adjustment. Color Temp There are 9300K/6500K/5800K/SRGB, and USER modes selectable Exit... -
Page 14: Peripherals Installation
3 Peripherals Installation Plug AC Power Cord on the Power Adapter a. Remove the base cover of the display. The power adapter should be installed in the bottom of the Base (as shown in the figure left). b. Plug the AC power cord to the power adapter. -
Page 15: Remove The Base Of The Monitor (Installation For Vesa Mount)
Remove the base of the Monitor (Installation for VESA Mount) The users can install the monitor on the wall with the standard VESA mount (75mm). Make sure that the LCD TV mount comes with a VESA compliant mounting holes pattern. Please contact the provider of the LCD Mount before installation. -
Page 16: Install Optional Rear Top Mount Customer Display
Install Optional Rear Top Mount Customer Display a. Secure the screws of customer display Securing Screws on the base. There are 2 securing holes for installing the Customer Display Power Source COM Port b. Plug the cable to a free COM port of the computer and connect the extension power cable to the power source. -
Page 17: Installing Touch Screen Driver
4 Installing Touch Screen Driver Please download the latest driver from TYSSO official website. Extract the compressed file and double click the folder “Driver & Utility” as below: There are categorized folders of Peripherals and Touch Screen drivers (Touch Driver). -
Page 18: Install The Driver Of Resistive Type Touch Panel
Install the Driver of Resistive Type Touch Panel To install the drivers of Resistive Touch Panel: Double click the folder “Touch Driver” to access the subfolder. There are drivers of Resistive type and Projective Capacitive type touch screen. To install the driver for Resistive type, select (double click) the folder “Resistive Touch”... - Page 19 Select the subfolder according to the operating system installed. (for example: select “Win 7 & Vista & XP & 2K & ME98-32bits” for the Windows XP 32-bit version) Double click the file “Setup.EXE” to start the installation. Click “Next” to start the installation.
- Page 20 Select the destination folder and click “Next” to continue. COM port (RS-232) driver installation. If the touch screen is for RS-232 interface, please click the checkbox “Install RS232 driver” additionally to install the driver. Click “Next” to continue.
- Page 21 Click “Install” to start the installation. Installation completed. Click “Finish” to exit.
- Page 22 Restart the system. Click “OK” to proceed. m. Installation completed. There is an icon on the screen for quick launch.
-
Page 23: Touch Screen Calibration (Resistive Type)
Touch Screen Calibration (Resistive Type) There is a Utility “Touch Tool” for Touch Screen Calibration. Double click the icon to access the utility. User can perform 4-point-calibration by selecting the function “4 pts calibration". - Page 24 There are 4 calibration points on the screen. Tap the blinking mark to complete the first calibration point. Proceed to the next mark and complete all calibration points The calibration is completed; tap the icon “Save” to save the setting. Tips: Advanced 9-point/25-point Calibration...
- Page 25 There are advanced 9-point calibration and 25-point calibration for more accurate calibration demands. Access “Advance” menu, and select either “9 pts linearization” or “25 pts linearization” to calibrate your touch screen.
