USER
MANUAL
Installation Addendum
Long Range
Repeater
For Vantage Pro2 , Vantage Pro2 Plus , Vantage Vue ,
Envoy8X , Weather Envoy , and Vantage Connect
™
Product Number 7654 for use with antennas 7656 & 7660
Davis Instruments, 3465 Diablo Avenue, Hayward, CA 94545-2778 U.S.A. • 510-732-9229 • www.davisnet.com
™
™
®
R
™
R
R
Advertisement
Related Manuals for DAVIS 7654OV
Summary of Contents for DAVIS 7654OV
- Page 1 For Vantage Pro2 , Vantage Pro2 Plus , Vantage Vue , ™ Envoy8X , Weather Envoy , and Vantage Connect ™ Product Number 7654 for use with antennas 7656 & 7660 ® Davis Instruments, 3465 Diablo Avenue, Hayward, CA 94545-2778 U.S.A. • 510-732-9229 • www.davisnet.com...
- Page 2 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modification not expressly approved in writing by Davis Instruments may void the warranty and void the user's authority to operate this equipment. FCC ID: IRDWW765Y...
- Page 3 Welcome! ™ The Long Range Repeater can be used with any wireless Vantage Pro2 or Vantage Vue transmitting station to re-transmit to a Vantage Pro2 compatible receiver (Vantage Pro2 or Vantage Vue console; Vantage Connect, Weather Envoy or Envoy8X, or a standard Wireless Repeater).
-
Page 4: Repeater Board Contents
Repeater Board Contents The board contained within the repeater enclosure has the following contents: Transmitting Receiving Antenna Antenna Solar Power Tab AC Adapter Cable Cable Battery Compartment External Antenna Connectors Status 1 2 3 4 5 6 7 8 Transmitter DIP Switches Repeater First In Chain... - Page 5 The components unique to the Long Range Repeater board are: • Transmitting Antenna Cable — Connects the repeater to the external transmitting antenna. • Receiving Antenna Cable — Connects the repeater to the external antenna receiving a station or repeater signal. Additional Tools for Setup In addition to the tools required for standard wireless repeater installation, the following additional tool is required to set up and install the long range repeater:...
- Page 6 Note: Davis Instruments sells FCC Type approved antennas for the long range repeater. These antennas are available for US customers only. US customer MUST use Davis antennas. Overseas customers are responsible for procuring their own long range antennas for use with the long range wireless repeater that comply with local regulations.
- Page 7 Yagi Antenna (radiation pattern 360 ) (radiation pattern +/- 25 ) The Davis long-range omni antenna transmits and receives data in a radiation pattern of the same radiation pattern as a standard Vantage Pro2 dipole antenna. The Yagi °, antenna transmits and receives data packets in a 50 beam of the front of the Yagi °...
- Page 8 To determine which antenna or antenna combination is needed for your network: • The Yagi antenna is the most powerful and will give the longest range. However, you can only use it if the data is being received from or transmitted to stations within a 50°...
-
Page 9: Antenna Configurations
Antenna Configurations When designing your system, consider the need for increased range as well as the need for directionality. Keep in mind which antenna on your long-range repeater is the receiving antenna and which is the transmitting antenna. Below is an example of a system that uses a standard repeater and a long-range repeater with an omni antenna receiving and a Yagi antenna transmitting. - Page 10 Mounting the Repeater and External Antennas The antenna configuration and long-range repeater can be mounted on a pole. Use the provided U-bolts for the wireless repeater and the U-bolts provided for each antenna type to install them all to a pole. Note: To accommodate your antenna configuration (omni and Yagi or Yagi and Yagi), mount the antennas first before mounting the wireless repeater enclosure.
- Page 11 4. Using an adjustable wrench or 1/2" wrench, tighten the nuts. 5. Place the second U-bolt around the pole and through the two holes at the bottom of the shelter. 6. Put a flat washer, a lock washer, and a hex nut on each bolt end, and tighten the hex nuts so that the Yagi remains in place, but can still be adjusted.
- Page 12 Two Yagi Antenna Combination Assembly The Yagi and Yagi assembly should be performed from the bottom antenna (Yagi) up to the top antenna (Yagi) so that the Yagi antenna can be installed flush to the top of the pole. Note: Be mindful of which antenna is to be the receiving antenna is and which is to be the transmitting antenna 1.
- Page 13 Installing a Repeater on a Pole Refer to the following illustrations to install the repeater and antennas on a pole: 1. Place the repeater enclosure on the pole somewhere Flat below the antennas that Washer makes it easy for the antenna cables to be routed around.
- Page 14 Connecting External Antennas to the Repeater It’s important to be mindful of which antenna you have chosen to be the receiving antenna and which to Tip: be the transmitting antenna. Once the repeater, and both external antennas have been attached to a pole and positioned, the antennas should be attached to the respective antenna cables in the wireless repeater enclosure.
-
Page 15: Specifications
Specifications Complete specifications for all of the Vantage Pro2 weather products as well as the wireless repeater are available in the Weather Support section of our website: http://www.davisnet.com/support/weather/ General Operating Temperature....-40 to 150° Fahrenheit (-40 to 65° Celsius) Non-Operating Temperature . -
Page 16: Contacting Davis Technical Support
Davis Instruments Corp., Hayward, CA. © Davis Instruments Corp. 2019. All rights reserved. Davis Instruments Quality Management System is ISO 9001 certified. Information in this document subject to change without notice. ® 3465 Diablo Avenue, Hayward, CA 94545-2778 U.S.A.
