DAVIS 7614 Installation Manual

The Wireless Repeater receives data from a Wireless Weather Station sensor
array and re-transmits it to the console. The repeater serves to extend the
transmission range and improve reception between the sensor array's trans-
mitter and the console's receiver.
One repeater can send data to any number of Monitor II or Wizard III consoles,
as long as each console contains a receiver. It can also receive and re-transmit
data from up to 8 sensor arrays, as long as each array has a transmitter set to a
unique ID code.
The repeater's flexibility allows you to put together your weather system in a
number of different ways. The most common setup is to plant the repeater in
between a transmitter and a receiver to improve reception. Another possibility
is to plant a series of repeaters to carry the transmitter's signal over a longer
distance, or around obstacles.
Note: The Wireless Repeater operates on a low power frequency that does not require you to obtain
an FCC license.

Installing the Wireless Repeater

How you go about installing the repeater depends on how many repeaters and
transmitters you plan to install. The first section below will discuss the most
common and simplest installation—that of one transmitter, one repeater and
one receiver. The following section will discuss daisy-chaining the repeaters in
succession to increase the range.

Single Transmitter, Single Repeater Installation

If you have just one sensor array (with transmitter) and just one repeater, sim-
ply follow the instructions below to install your system.
W i r el ess Repea t er
In s t a l l a t i o n Ma nua l
Product # 7614 & 7615
