MT-POWER AUDIO PMA-180-6 User Manual

MP3 Module
1 2 3
MP3 digital players
SD IR
USB
MODE PLAY STOP REPT PREV NEXT

Function Buttons

SD
MODE PLAY STOP REPT PREV NEXT
a
a
MODE
Press "Mode"button to switch between Bluetooth,FM,USB and SD mode.
Bluetooth Mode: Press "Mode" to enter. Switch on your Bluetooth and search for the
"Bluetooth" to connect it to your device.
FM Mode: Press "Mode" to enter. Press "PLAY" to auto search and save the channels.
b PLAY
Press to play or pause the track.When in FM mode,press to auto search and save channels.
c
STOP
Press to stop playing. When in SD/USB mode, press to enter the menu.
d REPT
Press to switch the play mode, such as in order or shuffle.
e
PREV
Short press for previous track and long press to turn down volume.When in FM mode,
short press for previous channel.
f NEXT
Short press for next track and long press to turn up volume.When in FM mode, short press
for next channel.
3
1 SD Card Slot
Built-in player will read music once the card is
inserted.
2 USB Input
Built-in player will read music once the USB flash
drive is inserted.
3 LCD Display
Mode Status will be shown on the display.
MP3 digital players
IR
USB
c e
b d f
PMA-180-6 / PMA-240-6
PMA-180-6 / PMA-240-6
PMA-180-6 / PMA-240-6
PMA-360-6 / PMA-500-6
MP3 digital players
2
ON SIG CLP
1
SD IR
SP1
POWER
USB
MODE PLAY STOP REPT PREV NEXT
TREBLE
BASS
3 3 3 3 3 3
4 2 4 2 4 2 4 2 4 2 4
5 1 5 1 5 1 5 1 5 5
1
SP2 SP3 SP4 SP5 SP6
BASS LINE1 LINE2 LINE3/MP3 MIC1 MIC2 PROMPT MIC2
