Martin Yale J1811 Manual

Jiffy Padding Press
1.0

Introduction

Thank you for selecting the Martin Yale Model J1811Jiffy Padding Press. We recommend that you
familiarize yourself with the Jiffy Padding Press by carefully reading these instructions. Thorough
understanding of the information contained within these instructions will help to eliminate most operator
associated errors and ensure years of trouble-free performance.
2.0

Assembly

2.1 Locate all loose parts in the package (refer to parts list and diagram).
2.2 Mount the door handle using the two screws supplied.
2.3
Mount the paper clamps to the sides with the knobs and washers as shown in the
diagram. The rubber tips on the thumbscrews face downward and the nylon washers go
between the knobs and side frames.
3.0

Operation

NOTE: For best results, all material should be jogged before padding. Martin Yale Model
400 or Model 4200 Jogger is recommended.
3.1 Drop the door in place; the bottom edge into the slot on the Frame and the top
edge over the Tie Rod.
3.2
Square the paper into the press against the door. Place the pressure plate on
the top of the paper stack against the door.
3.3 Lower the Paper clamps to the pressure plate and tighten the hand knobs. Use
the thumbscrews to apply additional pressure. Do not use tools such as wrenches
or pliers!
3.4 Remove the door and apply padding compound to the facing edge of the paper
stack. When dry, release the clamps to remove pad.
3.5 For Carbonless Paper
Pressure plate is constructed so that it can be set on the edge of the paper for little
penetration or moved away from the edge so that the carbonless padding compound can
penetrate further into the sheet. If you are doing snap-outs in carbonless forms, you can
move the pressure plate in about 1/4 " and the padding compound will penetrate just as
we'll as if you used a tipping machine.
4.0

Maintenance

Clean unit after use with warm, soapy water. Do not use the same brush for regular and carbonless
padding compounds. A paper liner can be used to minimize clean up.
M-S027082
251 Wedcor Drive • Wabash, IN 46992
Phone (260) 563-0641 • Fax # (260) 563-4575
Website: www.martinyale.com • Email: info@martinyale.com
Model J1811
Rev. 6 10/18/12
