3/8" IMPACT WRENCH
PIN CLUTCH COMPOSITE TYPE
Model 91831
ASSEMBLY AND OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
®
Copyright 2004 by Harbor Freight Tools
. All rights reserved. No portion of this
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for U.S. General Air Superiority 91831
Summary of Contents for U.S. General Air Superiority 91831
- Page 1 3/8” IMPACT WRENCH PIN CLUTCH COMPOSITE TYPE Model 91831 ASSEMBLY AND OPERATING INSTRUCTIONS ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at: http://www.harborfreight.com TO PREVENT SERIOUS INJURY, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE. ®...
-
Page 2: Product Specifications
PRODUCT SPECIFICATIONS Item Description Drive Size 3/8” Square Drive Free Speed 10,000 RPM Maximum Torque 260 Ft./Lbs Blows Per Minute 1,300 Maximum PSI 90 PSI Cubic Feet Per Minute 4.0 CFM @ 90 PSI Anvil Retainer Type Hog Ring Air Inlet Size 1/4”-18 NPT Inlet Screen 20-Mesh or Finer... -
Page 3: Work Area
WORK AREA Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. Do not operate pneumatic tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Pneumatic tools create sparks which may ignite flammables. -
Page 4: Specific Safety Rules
Do not force the tool. Use the correct tool for your application. The correct tool will do the job better and safer at the rate for which it is designed. Do not use the power tool if the Trigger does not turn it on or off. Any tool that cannot be controlled with the Throttle Lever is dangerous and must be re- placed. - Page 5 Use clean, dry, regulated, compressed air at 90 PSI. Do not exceed the recommended 90 PSI. Never use oxygen, carbon dioxide, combustible gases, or any other bottled gas as a power source for this tool. When connecting to the air supply: Prior to each use, if an automatic oiler is not used, add two drops of air tool oil (not included) into the Air Inlet (47) fitting of the Impact Wrench.
-
Page 6: Rear View
Select the 3/8” square drive Impact socket (not included) you wish to use, and insert the socket firmly onto the 3/8” Anvil (11) of the Impact Wrench. (See Figure A.) Turn the Forward/Reverse Valve (30) to the desired direction in which the tool will rotate. -
Page 7: Inspection, Maintenance, And Cleaning
To start the Impact Wrench, squeeze the Trigger (43). To stop the Impact Wrench, release pressure on the Trigger. (See Figure A.) NOTE: Before starting a job, always perform a test operation to determine the proper tightening time for the bolt or nut. If tightened for too long a period, the bolt or nut and socket may be overstressed, stripped, or damaged. -
Page 8: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 9: Assembly Diagram
ASSEMBLY DIAGRAM NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 91831 For technical questions please call 1-800-444-3353 PAGE 9...
