DIGITAL ZOOM FUNCTION

This function allows you to control the unit's ZOOM mode. The display shows the full magnification value
which is the product of the optical and digital magnification.
You can use the ZOOM function only in VIDEO and PHOTO modes.
To activate the zoom, briefly press the ZOOM (4) button.
Cycle through the available full magnification options by briefly pressing the ZOOM button: 4.5x>9x>4.5x
The digital zoom value is retained only during the current session.
When the unit is next switched on, the full magnification value reverts to 4.5x.
11
DISPLAY OFF FUNCTION
This function deactivates the display, which allows you to eliminate light exposure caused by the glowing
display.
You can operate the DISPLAY OFF function in two modes: VIDEO and PHOTO.
To turn the display off, press and hold down the ON (2) button for more than a second.
The message Display off appears on the black display.
To activate the display, press briefly the ON button.
When the DISPLAY OFF function is activated:
All controls are inactive (except for the ON button).
Video recording continues (if video was recording before activating the DISPLAY OFF function).
The Wi-Fi function keeps running.
The DISPLAY OFF function deactivates when:
The ON (2) button is briefly pressed.
The unit is connected to a PC via the USB port (selection of operating modes appears - "power" or "USB
Mass Storage Device").
17
12

USB CONNECTION

The unit can be connected to a PC via the USB port (9). The PC will detect the unit automatically, no driver
installation is necessary.
Connection options.
When the activated unit is connected to a PC via the USB port, one of the following connection options is
selected:
USB Mass storage device
If this option is selected, the unit is detected by the PC as a flash card. The unit switches to USB power.
This option is designed for use when working with files saved in the unit's memory. In this mode the unit's
functions are not available and the unit is "off".
Power
When this option is selected, the PC is used by the unit as an external
power supply. The external power icon appears on the display in
place of the battery charge icon .
The unit continues to operate, all functions are available.
Press the navigation buttons to cycle between connection options
(USB-> Power-> USB...).
To confirm the selection, briefly press the ZOOM (4) button.
960p 04:23pm
Active connection Inactive connection
option option
