Qdis QNAVI II -STD-MAIN-V6.1 Manual

Compatible with audi 3g/3g+ mmi vehicles
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Your best
partner
SUNE TECHNOLOGY CO.,LTD
better
for
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
driving
TEL:+88662292246 FAX:+88662288104
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
LAST UPDATED: 2012.05.25
Model: QNAVIⅡ-STD-MAIN-V6.1
Product code: QNAVIⅡ-STD-MAIN-1112-007
AUDI
Compatible with Audi 3G/3G+ MMI vehicles

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QNAVI II -STD-MAIN-V6.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Qdis QNAVI II -STD-MAIN-V6.1

Summary of Contents for Qdis QNAVI II -STD-MAIN-V6.1

  • Page 1 Your best partner SUNE TECHNOLOGY CO.,LTD better No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN driving TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99 LAST UPDATED: 2012.05.25 Model: QNAVIⅡ-STD-MAIN-V6.1 Product code: QNAVIⅡ-STD-MAIN-1112-007 AUDI Compatible with Audi 3G/3G+ MMI vehicles...

  • Page 2: Table Of Contents

    0. Contents Before installation 1.1 Specification 1.2 Features 1.3 Components 1.4 Exterior 1.5 Dip switch 1.6 Original buttons in car User interface 2.1 HOME 2.2 PHONE 2.3 MEDIA 2.4 SETUP Installation 3.1 Pre-installation notices 3.2 Installation diagram 3.3 MMI, CAN Wiring 3.4 Connect of the Smart Phone...
  • Page 3 1.1 System Spec. INDEX CONTENTS INDEX CONTENTS Telechips TCC8900 (ARM11), ROM NAND Flash MLC 128MB, DDR2 Main memory 600MHz 256MB External Windows CE 6.0 SDHC (~32GB) memory 2.0 (support for recognition of HOST, Display OEM LCD CLIENT ) U-BLOX5, 50 channels, NMEA 0183, SD card SD/SDHC (TOSHIBA SDHC Class6) 9600/1 (board rate/port)

  • Page 4: Features

    1.2 Features • Perfect compatibility with smart phones (iPhone, Android phones, possible for charging and play media) • TMC(Traffic Message Channel), user-intended function • Able to control all the function via Audi OEM MMI Controller (except for Navigation) • Various multimedia exteinsion (3*Video Input, 1*Rear Camera Input, 1*A/V Out) •...

  • Page 5: Components

    1.3.1 Components BOOT – N.C TMC – Option TOUCH IN cable * 1ea LVDS cable * 1ea (HTOUCH0007) (HLVDSC0013) POWER cable * 1ea (HPOWER0024) SUB board * 1ea (QCPASS0266) MODE switch cable* 1ea (HARETC0001) Connect with powercable LCD cable * 1ea (HLCDCA0015) Main board * 1ea USB extention cable * 1ea...
  • Page 6 1.3.2 Components iPOD cable * 1ea (Optional) (HARETC0029) SD CARD/Bluetooth interface* 1ea Microphone cable * 1ea (QCPASS0269) (MICPHO0001) GPS * 1ea (GPSANT0004) Speaker * 1ea (SPEAKE0001)

  • Page 7: Exterior

    1.4.1 Exterior main board Dimension/ ⓐ166mm * ⓑ108mm * ⓒ25mm ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ① USB USB cable connector ② SD/BT SD card slot/bluetooth sub board connector ③ REAR-CAM power cable of rear camera connected ④ A/V (IN/OUT) AV cable connector ⑤...
  • Page 8 1.4.2 Exterior SD card/ Bluetooth interface ④ ⑤ ⑥ Dimension/ ⓐ 87mm * ⓑ 57mm * ⓒ 18mm ① LED ② SD CARD SD card slot ③ RESET Not for driver’s use; ONLY for ⓑ manufacturer ④ TEST Not for driver’s use; ONLY for manufacturer ⑤...

  • Page 9: Dip Switch

    1.4.3 Dip switch #PIN Function Select DIP S/W ※ ON : DOWN, OFF : UP ▷ DIP S/W : 1  ON ▷ DIP S/W : 2  OFF ▷ DIP S/W : 3  ON(Q5 : Off) ▷ DIP S/W : 4  ON(using original NAVI) OFF : Q5 ON : Q7 and other available for compatibility Select...

  • Page 10: Original Buttons In Car

    1.4.4 Original buttons in car(3G+) ⑧ ⑩ ④ ⑥ ② ③ ① ⑨ ⑤ ⑦ ⑪ ⑫ Qnavi implementation ① Confirm ② Move leftward ③ Move rightward ④ Select left-up menu ⑤ Select left-down menu ⑥ Select right-up menu ⑦ Select right-down menu ⑧...
  • Page 11 1.4.4 Original buttons in car(3G) ⑥ ④ ③ ② ① ⑫ ⑧ ⑨ ⑬ ⑤ ⑦ ⑭ ⑩ ⑪ ⑮ Qnavi implementation ① Confirm ② Move leftward ③ Move rightward ④ Select left-up menu ⑤ Select left-down menu ⑥ Select right-up menu ⑦...

  • Page 12: User Interface

    2.1 User interface / MAIN MENU ※ Driver can control the Menu by touching screen and Original MMI ① ② ③ ④ ① NAVIGATION : Navigation function ② PHONE : Bluetooth function ③ MEDIA : Domestic(DMB, AV), Overseas(DVD, DTV-Option), USB, IPOD function ④...

  • Page 13: Phone

    2.2.1 User interface / PHONE ※ Before using this Bluetooth function, driver MUST take PAIRING process between the phone intended to use and the device ① ② ③ ④ ⑤ ⑦ ⑥ ③ ① ② ⑧ ⑧ ① Move to the main menu while music is played. ①...
  • Page 14 2.2.2 User interface / PHONE OPTION ① ② ③ ④ ⑤ ① PAIRING : Press driver’s password “0000” to register the phone on the device when you press “PAIRING” button. ② DEVICE LIST : List of Bluetooth device connected in the past ③...

  • Page 15: Media

    2.3.1 User interface / MEDIA MUSIC ② ① ⑥ ① ④ ② ③ ③ ④ ⑦ ⑤ ⑤ ⑧ ① MUSIC : Music output from USB ① Move to the main menu ② Close the current application (If you connect Android phone, It will be ③...
  • Page 16 2.3.2 User interface / MEDIA MUSIC ⑤ ⑥ ② ③ ① ⑦ ⑧ ④ ① Move to the previous music ② Play / Pause ③ Move to the next music ④ Stop ⑤ Rewind ⑥ Fast-forward ⑦ Repeat option – Repeat all, repeat one, none ⑧...
  • Page 17 2.3.3 User interface / MEDIA MOVIE & DVD & AV ② ① ⑥ ④ ② ③ ① ③ ④ ⑦ ⑤ ① Move to the previous media ① Move to the main menu ② Play / Pause ② Close the current application ③...
  • Page 18 2.3.2 User interface / MEDIA MOVIE & DVD & AV ② ① ① ② ⑤ ③ ③ ⑥ ④ ④ ⑦ ⑧ ⑨ ⑩ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑤ ⑥ ① Move to the main menu ① Move to the main menu ②...
  • Page 19 2.3.3 User interface / MEDIA IPod ① ② ④ ⑥ ⑤ ⑥ ② ③ ① ③ ⑦ ⑤ ⑦ ⑧ ④ ① Move to the previous music ① Move to the main menu ② Play / Pause ② Close the current application ③...
  • Page 20 2.3.3 User interface / MEDIA IPod ① ② ④ ⑥ ⑤ ⑥ ② ③ ① ③ ⑦ ⑤ ⑦ ⑧ ④ ① Move to the previous media ① Move to the main menu ② Play / Pause ② Close the current application ③...

  • Page 21: Setup

    2.4.1 User interface / SETUP REAR CAMERA ⑦ ⑥ ① ② ⑧ ③ ④ ⑨ ⑤ ① REAR CAMERA : Activation/inactivation of Parking Assistance System and control of its position (Refer to the right image.) ② VOLUME : Adjusting the sound volume of offered speaker ③...
  • Page 22 2.4.2 User interface / OTHER & VERSION FACTORY ① ② ③ ④ ① ② ③ ⑤ ⑥ ① DVD select : Select for using DVD model in Media ① FACTORY : Upgrade for the program, selecting (It is possible to control the DVD using touch ) the model of DVD and other model ②...

  • Page 23: Pre-Installation Notices

    3.1 Pre-installation notices During installation ignition key should be taken off and after all installation finish connect power • cable with interface for the last step Power cable should be separated when connecting interface. • Should be no any electronic devices or magnetic pole around installation place. •...

  • Page 24: Installation Diagram

    3.2 Installation diagram Control box OEM Monitor Original TOUCH cable Original LCD cable CAN-L offered LCD cable CAN-H TRIP (White) REAR MODE : Toggle S/W SAFE LVDS/TOUCH cable IR-AV2 IR-AV1 AUX-ON offered TOUCH cable POWER cable Micro Phone USB cable SD/BT cable Speaker REAR CAM...

  • Page 25: Mmi, Can Wiring

    3.3 MMI, CAN Wiring (3G MMI Model) * MMI Wiring *MMI Wire ※ This wire can be found behind of command unit (mostly color of the wire is white+green)
  • Page 26 3.3 MMI, CAN Wiring (3G MMI Model) * CAN Wiring *CAN Wires ※ CAN wires can be found behind of glove box (mostly color of the wires are Orange+yellow, Orange+Green)
  • Page 27 3.3 MMI, CAN Wiring (3G+ MMI Model) * MMI & CAN Wiring *MMI Wire *CAN Wires ※ MMI wire can be found behind of command unit (mostly color of the wire is YELLOW) ※ CAN wires can be found behind of glove box (mostly color of the wires are Orange, Green)

  • Page 28: Connect Of The Smart Phone

    3.3 Connect of the Smart Phone Android(Samsung, LG, HTC etc.) ① Connect Android Phone with USB Connector of ② Select the marked points on the Phone as shown QNAVI as using USB cable of Android Phone above. * Phone display can be different, depend on phone ③...
  • Page 29 3.3 Connect of the Smart Phone *IOS (Apple) ① Connect I-Pod or I-Phone with provided I-Pod cable ③ You can also watch media from Youtube or UCC ② Music, media files from phone will appear on the through Qnavi screen by A/V Out screen...

  • Page 30: Faq

     Use IPOD connection cable(optional) as shown right picture - In case of there is not I-pod cable in the glove box of the car  using by purchasing the FM Transmitter module or MOST AUX free module which are sold from QDIS(Optional)
  • Page 31 4. FAQ Q) I can not control the MENU using MMI A) You should check whether the prodcut(3G/3G+MMI) suitability with your car Make sure the MMI cable is properly connected Q) In Qnavi screen, I choose Navi button but I can not switch to original navigation A) Check the Dip S/W setting Q) The PAS line is not working A) You should check whether the product(3G/3G+MMI) suitability with your car...
