Asante 99-00900-US Quick Manual

With camera

Advertisement

Quick Links

Thank you for choosing
For first time installation, please make sure that the Asante products
and your router are within close proximity to each other.
Once configured, they can be moved to desired locations.
Asante Home Extender
ports and lights
Power
Wireless Pairing Light
Cloud Light
Wifi Wireless
Signal Strength
Connectivity Light
Light for Wireless
Ethernet port
to connect to your
Factory default reset button
personal router
(hold down for 6 seconds
Power
to reset to default)
Step 1
Connection to the router
Using the RJ45 Ethernet cable provided, connect
the Asante Home Extender to a LAN port on your router.
LAN port
Asante Garage Door
Opener with Camera
ports and lights
Wifi Wireless
Signal Strength
Power
Connectivity Light
Light for Wireless
Fastening
wheel
Mounting
hole
Connection to
Power
Garage Door
Reset button
Wall mount button
Step 2
Power
1. Connect the power to Asante Home Externder
and make sure power light comes on.
2. Cloud light comes on usually after 1 to 3 minutes
depending on the Internet connection.
Step 3
Download app and device discovery
* Connect Smartphone to same WiFi router that Asante Home Extender
is connected to.
1. Download free app from Apple Store or Google Play
Simply search for Asante Smart Home
2. Create an account and sign in
3. Claim your first Asante Home Extender when prompted
* If your Smartphone can not connect to same WiFi router, use the
procedure below to manually add the device.
1. Login to app and click the + sign as shown
2. Enterthe MAC address that appears on the back of Asante Home Extender
in the fields provided and click on apply.
Step 4
Setup of Garage Door Opener with Camera
1. Connect the power to your new Asente Garage Door Opener with Camera.
2. LED lights on Asente Garage Door Opener with Camera will start to blink
indicating WiFi pairing with Asante Home Extender.
3. Asante Home Extender pairing light will blink until the wireless connection has been
established.
4. Claim your first Garage Door Opener with Camera when prompted in the app.
5. Disconnect the power and move it to you desired location to prepare for installation
Step 5
Attaching Garage Door Opener with Camera to your
current garage door wall mount button
We recommend to unplug your garage door electric motor from
the AC power during the installation.
Each Garage Door Opener with Camera can control up to two garage doors.
1. Using one set of wires (provided), insert tips into the green connector.
