Asante Garage Door Opener With Camera Kit Quick Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Thank you for choosing
For first time installation, please make sure that the Asante products and your
router are within close proximity to each other. Once configured, they can be
moved to desired locations.
Power
Wireless Pairing Light
Wifi Wireless
Connectivity Light
Ethernet port to
Power
connect to your
personal router
Step 1

Connection to the router

Using the RJ45 Ethernet cable provided,
connect the Asante Home Extender to a LAN
port on your router.
LAN port
Cloud Light
Signal Strength
Light for Wireless
Factory default reset
button (hold down for 6
seconds to reset to default)
Asante Garage Door
Opener with Camera
ports and lights
Wifi Wireless
Connectivity Light
Power
Reset button
Step 2
Power
1. Connect the power to Asante Home Extender and
make sure power light comes on.
2. Cloud light comes on usually after 1 to 3 minutes
depending on the Internet connection.
Signal Strength
Power
Light for Wireless
Fastening wheel
This wheel is meant
to move freely to be
able to remove and
install camera while
the wires are still
attached.
Mounting
hole
Connection to Garage
Door Wall mount button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Garage Door Opener With Camera Kit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asante Garage Door Opener With Camera Kit

Summary of Contents for Asante Garage Door Opener With Camera Kit

  • Page 1 Thank you for choosing For first time installation, please make sure that the Asante products and your router are within close proximity to each other. Once configured, they can be moved to desired locations. Asante Garage Door Opener with Camera...
  • Page 2 Login to app and click the menu button as shown Click on the overflow button and select Add Home Extender Enter the MAC address that appears on the back of Asante Home Extender in the fields provided and click on SUBMIT...
  • Page 3 For wiring instruction of wall mount button please see “Wall Mount Buttons Reference Guide” (One pair of wire needed for one door) 3. Reconnect the power to your garage door motor and to Asante Garage Door Opener with Camera. 4. Wait until the WiFi lights on Garage Door Opener with Camera are established.
  • Page 4 Asante Home Extender wireless bridge mode can extend your wireless coverage in a large size property. For areas larger than 5000 sq.ft, consider placing the Asante Home Extender in a central location to bridge Asante devices into your home router. Otherwise we strongly recommend using the Ethernet wired mode. If you still want to use the wireless option, please follow the procedure below.
