- Page 1 GHD BENCH...
- Page 2 ® accessories that make a difference www.xeniosusa.com xenios usa - GHD BENCH Thanks for choosing a Xenios USA product! ®...
- Page 3 ® accessories that make a difference www.xeniosusa.com EXPLODED DRAWING...
-
Page 4: Part List
® accessories that make a difference www.xeniosusa.com PART LIST PART N° DESCRIPTION Q’TY Rear bottom tube Bottom connect tube Front upright frame Slide pipe group Rear upright frame Adjustable upright support Adjustable for pedal Pedal Foam tube Cushion Fixed group Reinforcement steel plate Reinforcement steel plate-short Hex bolt M 10x80... - Page 5 ® accessories that make a difference www.xeniosusa.com how to assembly STEP 1 Attach Rear bottom tube (01) to Connect bottom tube (02) using Reinforcement steel plate (09), Hex bolt M 10x80 (10), Washer Ø 10 (13) and Nylon nut M 10 (15). Attach Rear upright frame (05) to Connect bottom tube (02) using Hex bolt M 10x90 (26), Washer Ø...
- Page 6 ® accessories that make a difference www.xeniosusa.com STEP 2 Slide Adjustable upright support (06) onto the Slide pipe group (04), Secure them using Spring knob (16). Attach Front upright frame (03) to Connect bottom tube (02), Make sure through the round tube from Slide pipe group (04) into the hole on the Front upright frame (03), Fixed them using Reinforcement steel plate (09), Hex bolt M 10x80 (10), Hex bolt M 10x25 (11), Washer Ø...
- Page 7 ® accessories that make a difference www.xeniosusa.com STEP 3 Attach Cushion fixed group (08) to Rear upright frame (05) using Cross recessed countersunk head screws M 10x25 (27), Washer Ø 10 (13) and Nylon nut M 10 (15). Attach Cushion (24) to Cushion Fixed group (08) using Hex bolt M 8x20 (12) and Washer Ø 10 (14). Slide Adjustable for pedal (07) onto the Adjustable upright support (06).
- Page 8 While every effort has been made to ensure that all graphic representations and descriptions of goods available from XENIOS USA correspond to the actual goods, Xenios USA and/or its dealers and/or its international agents are not responsible for any variations from these descriptions. Error & omissions excepted.
