Thomas & Betts Reznor LDAP 1200 Installation & Operation Manual

Indirect fired, indoor, downflow, packaged heaters
Hide thumbs
Table of Contents

Advertisement

Quick Links

Table of Contents
Warnings ......................................... 1
Installation/Operation ............... 2-29
Check/Test/Startup .................. 30-31
Accessories ..................................... 32
Maintenance/Service ............... 32-40
Index (by page)
Burners ....................................... 13, 33
Burner Orifice ................................... 35
California Warning Label .................... 2
Clearances ........................................... 6
Installation Codes ............................... 2
Combustion Air .................................... 6
Confined Space .................................... 6
Destratification ................................. 18
Dimensions .......................................... 4
Electrical Connections ..................... 13
Fan ............................................. 20, 36
Fan Control (Destratification) .... 18, 38
Fan Motor .................................... 21, 36
Gas Piping and Pressures ................... 10
Gas Valve ...................................... 21, 37
General ................................................ 2
Hazard Intensity Levels ...................... 2
Heat Exchanger Maintenance ........... 33
High Altitude .................................. 3, 12
High Limit Control ...................... 17, 38
Ignition System ........................... 18, 35
LED Flash Codes ............................... 38
Limit Control .............................. 17, 38
Location (Heater) ................................ 7
Louvers ................................... 3, 10, 32
Maintenance Schedule ................ 32-33
Nozzle (Option) ............................ 3, 32
Pressure Switch
(Combustion Air) ............... 5, 17, 37
Replacement Parts .... See Form P-LDAP
Sound Data ........................................... 8
Startup ................................................ 30
Suspending Heater .............................. 8
Technical Data ..................................... 4
Thermostat (Option) .......................... 14
Throw Data .......................................... 7
Transformer ...................................... 38
Troubleshooting ......................... 38-40
Uncrating and Preparation ................. 3
Valve Outlet Pressure ......................... 12
Vent System Maintenance ................ 38
Venter Motor (Heat Section) ............ 35
Venter Motor (Main) ........................ 36
Venting ............................................... 26
Wall Mounting ..................................... 9
Warranty .............................................. 2
Weights ................................................ 8
Wiring Diagrams .......................... 22-25
CQS
Page
If you smell gas:
1. Open windows.
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
The use and storage of gasoline or other flammable vapors and
liquids in open containers in the vicinity of this appliance is
hazardous.
WARNING: Improper installation, adjustment, alteration, service,
or maintenance can cause property damage, injury, or death. Read
the installation, operation, and maintenance instructions
thoroughly before installing or servicing this equipment.
WARNING: Gas-fired appliances are not designed for use in
hazardous atmospheres containing flammable vapors or
combustible dust, in atmospheres containing chlorinated or
halogenated hydrocarbons, or in applications with airborne silicone
substances. See Hazard Levels, page 2.
WARNING: Should overheating occur, or the gas supply fail to
shut off, shut off the manual gas valve to the appliance before
shutting off the electrical supply.
WARNING: Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to inspect
the appliance and replace any gas control that has been under water.
Installation/Operation FORM RZ-NA I-LDAP
APPLIES TO:
®
Reznor
Model
LDAP 1200
FOR YOUR SAFETY
FOR YOUR SAFETY
Form RZ-NA-I-LDAP, P/N 207733 (Rev 2), Page 1
Indirect Fired,
Indoor, Downflow,
Packaged Heaters
