4. TOGGLE MODE (DEFAULT)
Pushing the pad from one position to the other will toggle the status of a
load, i.e. when the light is o , pushing the pad will turn on the light, and
vice versa.
5. ON / OFF MODE
To enable or disable the ON/OFF Operation
mode, press and hold the set button for
15 seconds until the LED blinks.
Push the top button to turn on your light and push the bottom to turn it o .
ON
Push pad to
toggle on / o
SET
Button
CR 2032
SET
+
Button
Red
LED
OFF
Advertisement
Table of Contents
Related Manuals for SkylinkHome TB-318
Summary of Contents for SkylinkHome TB-318
- Page 1 4. TOGGLE MODE (DEFAULT) Pushing the pad from one position to the other will toggle the status of a load, i.e. when the light is o , pushing the pad will turn on the light, and vice versa. Push pad to toggle on / o 5.
- Page 2 6. BRIGHTNESS CONTROL OPERATION Besides turning on and o a load, you may also control the brightness of a light if the receiver module and the light bulb is dimmable, i.e. either incandescent light or dimmable compact uorescent light. To change the brightness, rst turn on the light by pushing the pad. Then, press and hold the pad after the light is on will change the brightness of the light.
