- Page 1 Customer Service: Green Bike – Electric Motion. Main Office: 7057 Reseda Blvd, Reseda CA 91335 Phone: (818) 578-3665 Email: office@GreenBikeElectric.com Website: GreenBikeElectric.com Folding Electric Bicycles – MODEL HF 201 Instruction Manual...
- Page 2 Instruction Manual Green Bike – Electric Motion Congratulations on you're newly purchased! Joining Greenbike’s Go Green revolution will open your doors to a whole new Green Bike – Electric Motion world of freedom! greatly values the quality of our products, giving you value for your money, friendly and professional service, and safety for the rider above all else.
- Page 3 1. Brake Handles 2. Grips 3.Handlebars 4. Adjustable Stands 5. Display 6. Gear Shifter 7. Front Brake Cable 8. Rear Brake Cable 9. Cable selector 10. Headlight and horn 11. Front mud-guard 12. Tire and inner tube 13. Front Wheel. 14. Frame 15. Front fork 16. Front wheel chain (crank) 17. Chain shield 18.
- Page 4 - Be sure that the locking hinges of the seat and handlebars are locked before starting the trip. - Check the condition of the brakes frequently and adjust when necessary. Braking range on a dry road is 13 feet and on a wet road can reach 50 feet. Keep more distance on a wet road.
- Page 5 - Damage to either the spokes, wheel, or tires resulting from typical cycling injuries and accelerated wear of the battery which may result from travel with a curved wheel are not covered by the warranty. Folding the Bike - The bike can be folded for storage at home or in the trunk of the car. - The folding time is only 10 seconds.
- Page 6 Before You Start to Ride Raise the seat as shown in Figure 3 and insert the battery into place and lock it. Picture 3 Picture 4...
- Page 7 KH-DX-M1 : Ebike Display with thumb throttle Material Caser and Cover: ABS LCD window: PMMA Overview Manipulation: Integrated with one thumb throttle for speed regulation Equipped with 3 press buttons to switch display content and make parameter settings Protocol: This display uses UART protocol, throttle signal is sent by UART to controller Speed：...
- Page 8 Real-time SPEED， MAX SPEED， Average SPEED 4. Battery level: Indicates the battery level in real time Light control: ON/OFF : Press button for 3 seconds to switch on/off 6. Assist level: From 1 to 3, press up or down button to change assist level (could be set to more levels) 7.
- Page 9 Battery level: 5 levels, Speed: Average SPEED/MAX SPEED/Real-time SPEED Speed unit: KMH/MPH 6km/h walk mode: Assist level: assist level 1~3. Head light icon: shows up when head light and back light are on. Distance: Trip/ODO. Error code: “ERR” and code show up when there is error. Operation instructions It is equipped with 3 press buttons: “UP”...
- Page 10 2. Different Speed display: Long press Power switch different speed information, Real time speed (SPEED) → Max speed（ MAX SPEED）→ Average speed (AVG SPEED)
- Page 11 3. ODO/TRIP/ Ride time/Error Code Short press to switch ODO/TRIP/Ride time/Error Code Trip (Single trip distance)→ODO (Accumulated distance)→TM (Ride time)→ERR (Error Code) 4. Assist level Short press to change assist level, default value is level 1...
- Page 12 5. Light control Long press for 3 seconds turn on/off the head light and rear lamp 6. 6km/h mode When the bike is stopped, long press , will enter 6km/h mode, the speed will be 4.5~7.5km/h according to different road conditions, will show up on screen, long press again or short press to quit 6km/h mode.
-
Page 13: Parameters Setting
Parameters setting When the display is powered on, long press , will enter parameter setting mode , in this mode, user can change parameter values . long press again will quit parameter setting mode or no operation during 10s will also quit this mode. - Page 14 • P02-KMH / MPH: Short press to Switch Kmh/MPH. • P03-Battery rated voltage: Short press to switch 24V, 36V,48V, Default value is 36V. • P04-Auto shutdown time: short press to switch from 0 to 60, it is the time (in minutes) to shut down the screen automatically if no operation, 0 means never shut down, Default value is 10 minutes...
- Page 15 • P05-Number of Assist levels: Short press to change level 0->1->2. assist levels : 0: 3 assist levels 1: 5 assist levels 2: 9 assist levels • P06-Wheel size selection: short press to switch wheel size, in inch, step: 0.1 inch...
- Page 16 • P07-Number of magnets for speed sensor: short press to switch from 1 to 100. • P08-speed limit: short press to set the speed limit from 0 to 100Km/h, 100 means no limit. In this e-bikes the controller is limited to 20 mph with throttle because the USA regulations.
- Page 17 • P10-Driving mode selection: short press to switch from 0->1->2. 0： Assist mode (throttle does not work, only pedal assist); 1: Electrical driving mode(only throttle works, pedal assist does not work) 2: Both assist and Electrical driving mode (Not available if in zero speed start and electrical driving mode •...
- Page 18 • P12-assist starting power setting: short press to switch from 0 to 5. • P13-Assist magnetic disc types: to switch from 5->8->12 ， different numbers of magnets short press in the disc.
- Page 19 • P15-low voltage protection for controller : • P16-Reset ODO distance: long press during 5 seconds. • P18-Reset all parameters: 5 seconds, when it displays “SSSS”, all parameters reset to long press default values (except for the ODO distance).
-
Page 20: Specifications
Specifications Power supply: 24V,36V, 48V Rated current: 10mA Max current: 30mA Leakage current after power off: <1uA Current supply to controller: 50mA Working Temperature： -18~65℃ Storage temperature： -30~80℃ Notices Power on and power off must keep an interval of at least 3 seconds, Please don’t press ”... - Page 21 Table 1- Error code definition When an error appears, display will notice users by different codes, please refer to table 1 for different codes : Code(Decimal) Signification Normal Low Battery level Motor error Throttle error Controller error UART receive error UART receive error The Electrical System is Now Ready! •...
- Page 22 • The bike must be locked with a massive lock and difficult to steal. It is recommended to take the battery with you. • Charging: The battery must be charged only with the charger supplied with the bike. A lithium battery is only charged by a charge to lithium batteries and not by other charger.
- Page 23 • In picture 6 you can see a stretched handle in optimal position. In addition, you can access any authorized bicycle shop to handle the mechanical parts of the bike but not the electrical parts. The electrical parts can only be handled by a workshop authorized by the importer. National safety regulations must be obeyed.
- Page 24 Mechanical and Electrical Components Electronic Specifications Frame 100% Aerospace aluminum 6061 Motor :HT 350 Watt Brushless (High Type folding electric bicycles Speed) Tires with light 2.125 20" made by reflectors Rims 100% double-sided aluminum Controller : (PAS) Front brake Green Bike - Hydraulic disk brake "Smart"...
- Page 25 Common Problems and Solutions • Problem 1: After turning on the main switch, the lights do not turn on and the bike does not move electrically. o Cause: The battery poles are not properly connected or a fuse is burned. Solution: Check the battery contacts if they are dirty and should be cleaned.
- Page 26 o Solution: After testing the power source (wall outlet) or replacing the charger, the charger and battery must be brought to a service center. Remember: Do not allow another rider on bike. Disconnect the charger from the power source at the end of each charge. Do not leave a bike / battery charging unattended.
- Page 27 Dear Client, Green bike – Electric Motion. welcomes you on the purchase of the model: HF 201– 48N / HF 202-48N electric bicycle is happy to be at your disposal for maintenance and fulfillment of manufacturer's warranty if necessary. Please carefully read the following warranty conditions. The warranty provided by Greenbike Company is a comprehensive warranty for all mechanical assemblies and all electronic components of the bike provided that the fault is caused by reasonable use and the bicycle is maintained according to the user manual alone.
- Page 28 Green Bike- Electric Motion reserves the right to decide whether to replace the damaged part with a new or renewed one at its discretion. Green Bike- Electric Motion reserves the right to cancel liability and refuse to provide service in the following cases: •...
- Page 29 Warranty Green Bike – Electric Motion , LEGEND48-HD I hereby inform you that I purchased a HF-201-48N) In the shop ____________________ Street and number _______________ City _______________ ZIP_______________ State______________ Invoice No. _______________ Date of purchase ___________________. Serial number of the bike (the number is stamped under the handlebar) ________________ (last 7 digits) Serial number of battery ______________________ (last 4 digits) I will ask you to activate for me the warranty for the bike I purchased...
