Please keep this instruction sheet for future reference,
as it contains important information.
Tool required for assembly: Phillips screwdriver (not included).
Requires three "C" (LR14) alkaline batteries for operation (not included).
Product features and decorations may vary from the pictures above.
Instructions
Product Number: 73408
Adult assembly is required.
™
™
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fisher-Price Baby Playzone Crawl & Cruise Playground
Summary of Contents for Fisher-Price Baby Playzone Crawl & Cruise Playground
- Page 1 ™ Crawl & Cruise Crawl & Cruise Crawl & Cruise Playground Playground ™ Playground Instructions Product Number: 73408 Please keep this instruction sheet for future reference, as it contains important information. Adult assembly is required. Tool required for assembly: Phillips screwdriver (not included). Requires three "C"...
- Page 2 Parts Activity Ring Ball Director Center Track Ball Director (Back Half) (Front Half) (In Folded Position) Bottom Track LB Top Rail LT Top Rail RT Bottom Track RB Track A Track B Track C Track D Mirror Tray Support L 6 Balls Ball Support R...
- Page 3 Consumer Information Battery Compartment Questions? We'd like to hear from you! Door Call Fisher-Price ® Consumer Relations, toll-free at 1-800-432-KIDS, Bottom View 8 AM - 6 PM EST Monday through Friday. Hearing- impaired consumers using TTY/TDD equipment, please call 1-800-382-7470.
- Page 4 (Back Half) Ball Director (Front Half) Ball Director (Front Half) • Locate the ball director front half (with the Fisher-Price ® #6 x " Screw logo on it). Note the labeling Shown Actual Size on the ball director front half (A, B, C and D).
- Page 5 Assembly Mirror Tray Ball Director Assembly Bottom Track RB RB Marking Tabs Center Slots Track • Place the bottom track RB on a flat surface with the RB facing you. • Insert the tabs on the ends of the mirror tray into the •...
- Page 6 Assembly Top Rail RT Top Rail LT Bottom Track LB Bottom Track RB #10 x 2 " Screw Shown Actual Size #10 x 2 " Screw Shown Actual Size • Place the bottom track LB on a flat surface with the LB facing you.
- Page 7 Ball Director Assembly • Position the side assembly labeled RT so that it curves toward you. • Hold the ball director assembly so that the Fisher-Price ® #8 x " Screw logo faces you. Note that the curve in both these parts Shown Actual Size form a half circle.
- Page 8 Assembly Activity Ring Latch Speaker Activity Ring Chute Latch • Press both side latches on the activity ring and lift the ring until it “clicks” (A). • Press both latches again and lower the ring until it “clicks” in place as shown (B). Base Assembly •...
- Page 9 Assembly • Insert two #10 x 2 " shoulder bolts through the base assembly and into the activity ring. Tighten the bolts with #10 x 2 " Shoulder Bolt a Phillips screwdriver. Do not over-tighten. Shown Actual Size • Insert two #10 x 2 "...
- Page 10 Standing Mode This mode is designed for babies who are walking and standing. To convert this toy to standing mode: Press both latches on the activity ring and lift the ring until it "clicks" into place. Push on the activity ring to be sure it is secure in its upright position.
- Page 11 Crawling Mode This mode is designed for babies who are crawling, sitting and learning to pull themselves up. To convert this toy to crawling mode: Press both side latches on the activity ring. Now, lower the activity ring until it "clicks" into place. Pull up on the activity ring to be sure it is secure.
- Page 12 Fisher-Price, Inc., a subsidiary of Mattel, Inc. East Aurora, New York 14052, U.S.A. Printed in Mexico ©2002 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
