Summary of Contents for Asus ROG STRIX XG258Q
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Notices ......................iv Safety information ..................v Care & Cleaning ..................vi Takeback Services ..................vii Chapter 1: Product introduction Welcome! ..................1-1 Package contents ................. 1-1 Monitor introduction ..............1-2 1.3.1 Front/side view ..............1-2 1.3.2 Back view ................ 1-3 1.3.3 GamePlus Function ............ -
Page 4: Notices
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Safety Information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer. • Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately. -
Page 6: Care & Cleaning
AEEE yönetmeliğine uygundur Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. • Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor surface with a lint-free, non-abrasive cloth. -
Page 7: Takeback Services
These documents are not part of the standard package. Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. - Page 8 viii...
-
Page 9: Welcome
Welcome! Thank you for purchasing the ROG gaming monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual experience... -
Page 10: Monitor Introduction
Monitor introduction 1.3.1 Front/side view 5-way) button: • Turns on the OSD menu. Enacts the selected OSD menu item. • Increases/Decreases values or moves your selection up/down/left/right. • Turns on the OSD menu when the monitor enters standby mode or displays the “NO SIGNAL“... -
Page 11: Back View
. This port is for connection with a DisplayPort compatible device. DC-IN port. This port connects the power cord. Earphone jack. This port is only available when an HDMI/DisplayPort cable is connected. Control buttons. ROG Strix XG258Q Series Gaming LCD Monitor... -
Page 12: Gameplus Function
1.3.3 GamePlus Function The GamePlus function provides a toolkit and creates a better gaming environment for users when playing different types of games. The crosshair overlay with four different crosshair options lets you choose the one that best suits the game you're playing. -
Page 13: Gamevisual Function
: More items are adjustable in the Color menu. • In the Racing/MOBA mode, the following function(s) are not user- configurable: ASCR, Saturation. • In the sRGB mode, the following function(s) are not user-configurable: Color Temp., Brightness, Contrast, ASCR, Saturation. ROG Strix XG258Q Series Gaming LCD Monitor... - Page 14 Chapter 1: Product introduction...
-
Page 15: Assembling The Monitor Arm/Base
Attach the LED projection cover to the stand. We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. To change the film on the LED projection cover, follow the illustration below. ROG Strix XG258Q Series Gaming LCD Monitor... -
Page 16: Cable Management
Cable management You can organize the cables with the help of the input/output port cover. • Arranging the cables • Using the input/output port cover : the cover can be attached or detached. Chapter 2: Setup... -
Page 17: Adjusting The Monitor
Tilt the monitor to its maximum angle. Pivot the monitor clockwise to the angle you need. 0° 90° 0° 120mm 90° It is normal that the monitor slightly shakes while you adjust the viewing angle. ROG Strix XG258Q Series Gaming LCD Monitor... -
Page 18: Detaching The Arm (For Vesa Wall Mount)
Detaching the arm (for VESA wall mount) The detachable arm of this monitor is specially designed for VESA wall mount. To detach the arm: Have the front of the monitor face down on a table. Remove the covers on where the monitor and the arm meet. Loosen the four screws on the back of the monitor and remove the arm/base. -
Page 19: Connecting The Cables
Turning on the monitor Press the power button . See page 1-2 for the location of the power button. The power indicator lights up in white to show that the monitor is ON. ROG Strix XG258Q Series Gaming LCD Monitor... - Page 20 Chapter 2: Setup...
-
Page 21: Osd (On-Screen Display) Menu
ROG Strix XG258Q GameVisual Scenery Mode Blue Light Filter Racing Mode Color Cinema Mode Image RTS/RPG Mode Sound FPS Mode Input Select sRGB Mode System Setup MOBA Mode MyFavorite User Mode MOVE/ENTER BACK EXIT ROG Strix XG258Q Series Gaming LCD Monitor... - Page 22 Blue Light Filter In this function, you can adjust the blue light filter level. DP 1920x1080@240Hz Racing Mode Aura OFF ROG Strix XG258Q GameVisual Level 0 Blue Light Filter Level 1 Color Level 2 Image Level 3 Sound Level 4...
- Page 23 Aspect Control : Adjusts the aspect ratio to Full or 4:3. • ASCR : Turns on/off the ASCR (ASUS Smart Contrast Ratio) function. • ELMB : Turns on/off the ELMB (Extreme Low Motion Blur) function. This function is available when the refresh rate is 100Hz, 120Hz, or 144Hz.
- Page 24 *For supported GPUs, minimum PC system and driver requirements, please contact the GPU manufactures. Sound Set the sound related setting from this menu. DP 1920x1080@240Hz Racing Mode Aura OFF ROG Strix XG258Q GameVisual Volume Blue Light Filter Mute Color Image...
- Page 25 • Power Indicator: Turns the power LED indicator on/off. • Power Key Lock: Enables or disables the power key. • All Reset : Selecting “Yes” allows you to restore the default settings. ROG Strix XG258Q Series Gaming LCD Monitor...
- Page 26 MyFavorite Loads/Saves all settings on the monitor. DP 1920x1080@240Hz Racing Mode Aura OFF ROG Strix XG258Q GameVisual Setting 1 Blue Light Filter Setting 2 Color Setting 3 Image Setting 4 Sound Input Select System Setup MyFavorite MOVE/ENTER BACK EXIT Chapter 3: General Instructions...
-
Page 27: Specifications Summary
Turkish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Thai, Indonesia, Persian) Accessories DP cable, HDMI cable, Power adapter, Power cord, Driver and Manual disc, Quick start guide, Warranty card, LED projection cover and changeable films, Input/Output port cover ROG Strix XG258Q Series Gaming LCD Monitor... -
Page 28: Troubleshooting (Faq)
Compliance and standards CB, CE, CU, CCC, UL/cUL, FCC, RCM, BSMI, VCCI, RoHS, WEEE, J-MOSS, ErP, PSE, CEL, Windows 7 WHQL, Windows 8.1 WHQL, Windows 10 WHQL, KCC, E-Standby, TUV- Flicker Free, TUV-Low Blue Light, UkrSEPRO, MEPS *Specifications are subject to change without notice. Troubleshooting (FAQ) Problem Possible Solution... -
Page 29: Supported Operating Mode
1280x768 60Hz 47.396KHz 1280x800 60Hz 49.306KHz 1280x800 60Hz 49.702KHz 1280x800 75Hz 62.795KHz 1280x960 60Hz 60KHz 1280x1024 60Hz 63.981KHz 1280x1024 75Hz 79.976KHz 1366x768 60Hz 47.712KHz 1440x900 60Hz 55.469KHz 1440x900 60Hz 55.935KHz 1440x900 75Hz 70.635KHz ROG Strix XG258Q Series Gaming LCD Monitor... - Page 30 1680x1050 60Hz 64.674KHz 1680x1050 60Hz 65.29KHz 1920x1080 60Hz 66.587KHz 1920x1080 60Hz 67.5KHz 1920x1080 85Hz 95.43KHz 1920x1080* 100Hz 113.3KHz 1920x1080* 120Hz 137.2KHz 1920x1080* (DP) 144Hz 158.11KHz 1920x1080 (DP/HDMI-2) 240Hz 291.309KHz 640x480P (HDMI) 59.94/60Hz 31.469KHz/31.5KHz 720x480P (HDMI) 59.94/60Hz 31.469KHz/31.5KHz 720x576P (HDMI) 50Hz 31.25KHz 1280x720P (HDMI) 50Hz...
- Page 31 ROG Strix XG258Q Series Gaming LCD Monitor 3-11...
