Webb WEPT360MM Original Instructions Manual

36cm petrol tiller; 56cm petrol tiller.

The manufacturer reserves the right to change the product speciﬁ cation and livery according to continues product improvements.

en - Original Instructions

Sales & Support: 01793 333212

Before use please read & understand this manual; paying particular attention to the safety instructions.

36cm Petrol Tiller

WEPT360MM

56cm Petrol Tiller

WEPT560MM

1938216001

1938217001

Table of Contents

Need help?

Do you have a question about the WEPT360MM and is the answer not in the manual?

Questions and answers

Summary of Contents for Webb WEPT360MM

Page 1 36cm Petrol Tiller WEPT360MM 1938216001 56cm Petrol Tiller WEPT560MM 1938217001 en - Original Instructions Sales & Support: 01793 333212 Before use please read & understand this manual; paying particular attention to the safety instructions. The manufacturer reserves the right to change the product speciﬁ cation and livery according to continues product improvements.
Page 2 INSTRUCTION MANUAL 11 July 19 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
Page 3: Table Of Contents
CONTENTS INTENDED USE SAFETY INSTRUCTIONS SPECIFICATIONS KNOW YOUR MACHINE ASSEMBLY OPERATION MAINTENANCE, CLEANING & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST DECLARATION OF CONFORMITY WARRANTY INTENDED USE The basic version of the equipment is a scarifier intended for private use, i.e. for use in home and gardening environments.
Page 4: Safety Instructions
INSTRUCTION MANUAL SAFETY INSTRUCTIONS Read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. Read &...
Page 5 GENERAL SAFETY RULES Before you put the machine into operation, you must read this instruction manual. When using this machine, observe the following safety instructions to exclude the risk of personal injury or material damage. Please also observe the special safety instructions in the respective chapters. Where applicable, follow the legal directives or regulations for the prevention of accidents in relation to the use of this machine.
Page 6 − After hitting an obstruction. Before restarting, search for damage on the machine and make repairs as necessary. If the machine starts vibrating unusually, it should be inspected immediately by an Approved Webb Service Dealer. 15. Switch the engine off: −...
Page 7 11. Maintain your machine. Check for misalignment or binding of moving parts, breakage of parts & any other condition that may affect the operation. If damaged, have the machine repaired by an Approved Webb Service Dealer immediately. Many accidents are caused by poorly maintained machines.
Page 8: Specifications
INSTRUCTION MANUAL SPECIFICATIONS Model WEPT360MM WEPT560MM Product Number 1938216001 1938217001 Working Width 360mm 560mm Working Depth 130mm Wheel Size Engine Petrol, 4-Stroke Air Cooled Engine Displacement 161cc Engine Power (Max) 2.9kW / 3000rpm Gross Torque (NM)@2600rpm Full Tank Capacity 1.3L Oil Tank Capacity 0.45L...
Page 9: Know Your Machine
KNOW YOUR MACHINE 1. Clutch Lever 2. Handle 3. Clutch Cable 4. Throttle Lever 5. Engine Speed Adjustment Cable 6. Drag Bar 7. Fender (Extended for 560MM) 8. Tine Assembly (Extra Set For 560MM) 9. Gearbox 10. Transport Wheel 11. Recoil Starter 12.
Page 10: Assembly
INSTRUCTION MANUAL ASSEMBLY Remove the machine and contents from the carton. Be sure the carton is empty before discarding. If you require any assistance with regards to the contents of the machine, contact us: Tel: 01793 333212 - Mon – Fri 8.00am – 5.30pm (excl. Bank Holidays) Email: customerservice@webbgardenpower.co.uk IMPORTANT INFORMATION NOTE: This product is a 4-stroke engine powered Tiller.
Page 11 HANDLE BAR Attach the handle bar to the handle bar support properly to align the assembly holes (x2) and then fix with • M8x45 bolt, washer & nut. DRAG BAR • First attach the drag bar to the drag bar holder, choose a proper height and then lock the drag bar with R‐type locking pin.
Page 12 INSTRUCTION MANUAL FENDER EXTENSION - (WEPT560MM ONLY) • Mount the fender extension to the fender and secure using nut and bolt. THROTTLE LEVER Mount the throttle lever to the right handle and secure with the bolt and nut supplied. •...
Page 13: Operation
OPERATION FUEL & OIL WARNING YOUR MACHINE IS SUPPLIED WITHOUT ENGINE OIL OR PETROL Operating the engine with insufficient oil within your fuel mixture, can have catastrophic consequences. Any failure caused by insufficient oil, will not be covered by the manufacturer’s warranty. Read instructions carefully.
Page 14 INSTRUCTION MANUAL ENGINE OIL Remove the oil filler cap with built in dipstick. Fill the engine with 4‐stroke SAE30 or 10W/30 air cooled lawnmower engine oil. DO NOT USE automotive or marine oil. The use of a funnel will aid the filling. The engine capacity is 0.45L, however we recommend the dipstick on the oil filler is dipped (without screwing into the filler neck) to ensure the oil level remains between the minimum and maximum marks on the dipstick.
Page 15 RUN/OPERATING POSITION As the engine warms, gradually move the throttle lever to the RUN position (B). • STOP POSITION - IN AN EMERGENCY Turn the throttle lever to the “STOP” position (C). • STOP POSITION - IN NORMAL USE • Release the clutch lever to DISENGAGED position and let throttle lever to "STOP"...
Page 16 INSTRUCTION MANUAL TILLER HEIGHT ADJUSTMENT CAUTION Before adjusting the handle, place the tiller on firm level ground to prevent the handle from collapsing accidentally. • To adjust the tiller height, loosen the adjuster, select the appropriate hole and tighten the adjuster. HEIGHT ADJUSTMENT SCREW TILLER DEPTH ADJUSTMENT...
Page 17 FRONT WHEEL Move the tiller to the work area with the front wheel, lift the handlebars up and ground the front • wheel. • When the tiller is used cultivate, move the wheel up. 1. pull the front wheel downward 2.
Page 18: Maintenance, Cleaning & Storage
INSTRUCTION MANUAL MAINTENANCE, CLEANING & STORAGE WARNING Improper maintenance & storage of the machine may void your warranty. Keep the machine clean for better and safer performance. Turn off the engine before performing any maintenance. If the engine must be run, make sure the area is well ventilated.
Page 19 ENGINE OIL CHANGE Drain the oil while the engine is still warm to assure rapid and complete drainage 1. Remove the oil filler cap and drain the oil. 2. Refill with the recommended oil and check its level. Oil capacity: See Specification section of this manual. Wash your hands with soap and water after touching used oil.
Page 20 INSTRUCTION MANUAL 3. Measure the plug gap with a feeler gauge. The gap should be 0.7‐0.8mm (0.028‐0.031 in), correct as necessary by bending the side electrode. 4. Attach the plug washer, thread the plug in by hand to prevent cross‐threading. 5.
Page 21: Trouble Shooting
CAUTION The engine must have completely cooled down before storing. NOTE: When storing any type of power equipment in an unventilated or material storage shed, − Care should be taken to rust-proof the equipment. Using a light oil or silicone, coat the equipment, especially cables and all moving parts.
Page 22 INSTRUCTION MANUAL PARTS DIAGRAM - WEPT360MM 1938216001...
Page 23 PARTS LIST - WEPT360MM 1938216001 Item No. Webb Part No. Description Qty Item No. Webb Part No. Description WE149‐661002 Handle Housing WE149‐91349 M8x40 Bolt WE149‐91441 M5x35 Bolt WE149‐661009‐039 Clutch Lever WE149‐666005 Right Tine Assembly WE149‐661007 Clutch Cable WE149‐662001 Gearbox WE149‐661005‐206 Left Handle WE149‐90063...
Page 24 INSTRUCTION MANUAL PARTS DIAGRAM - WEPT560MM 1938217001...
Page 25 PARTS LIST - WEPT560MM 1938217001 Item No. Webb Part No. Webb Description Qty Item No. Webb Part No. Webb Description WE149‐661002 Handle Housing WE149‐661005‐206 Left Handle WE150‐666007 Right Outer Tine WE149‐661004 Handle Grip WE149‐666005 Right Tine Assembly WE149‐90059 M8 Nut WE149‐662001...
Page 26 INSTRUCTION MANUAL PARTS DIAGRAM - ENGINE...
Page 27 PARTS LIST - ENGINE - PART 1 PARTS LIST - ENGINE - PART 2 Item No Webb Part No. Description Item No Webb Part No. Description WE151‐91365 M6x12 Bolt WE151‐91038 Stud Bolt WE151‐311101 Cylinder Head Cover WE151‐293601‐055 Fuel Cap Assembly WE151‐96161...
Page 28 EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Petrol 360mm Tiller Model(s): WEPT360MM Product No.: 1938216001 Type/Serial No. As per rating label on machine Engine Displacement: 161 cm Rated Engine Power: 2.9 kW / 3600 rpm...
Page 29 EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Petrol 560mm Tiller Model(s): WEPT560MM Product No.: 1938217001 Type/Serial No. As per rating label on machine Engine Displacement: 161 cm Rated Engine Power: 2.9 kW / 3600 rpm Tilling Width: 560 mm Complies with the following directives: Machinery Directive 2006/42/EC...
Page 30 INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the conditional manufacturer domestic warranty*. Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
Page 31 Webb (excludes Electric Handheld) & Webb Pro, 2 year conditional warranty from the original date of sale to the ﬁ rst domestic user. Webb Electric Handheld & Dynamic, Legacy & Heritage 1 year warranty from the original date of sale to the ﬁ rst domestic user.
Page 32: Warranty
It is the owner’s responsibility to ensure that their Webb machine is maintained at speciﬁ c intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
Page 33 Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.
Page 34 Service Record INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date...
Page 35 Email From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, oﬀ ers or just opinions, which may be used for marketing, research or analysis purposes.
Page 36 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY...
