INTRODUCTION
Congratulations on purchasing 10 CHANNEL LIGHT SWITCH PANEL LC-1006F IBIZA LIGHT. Prior to use, we
suggest that you carefully read all of the instructions.
FEATURES
10 lighted switches
CAUTIONS
1. The output is per channels 6A in 240V and has a resting power. The total continuous power rating is 20A/5000W
in 250V.
2. Never use this unit in a wet and/or dusty environment or in the open air.
3. It is not allowed to expose the appliance dripping –or splash water.
4. This device falls under protection-class I. Therefore it is not allowed to connect the plug to another socket-outlet
than a protection- class I socked – outlet.
FRONT
Power switches to turn equipment on and off, and FLASH push-buttons (unlatching)
REAR
Outlets: to plug equipment into.
OPERATION
1. Plug equipment into the outlets on the back of the unit.
2. Plug in the LC1006F into a power outlet.
3. Turn on the power switches on to equipment as desired (the switches will light when powered).
4. Press the Flash button to make the light effects flash occasionally and during a short period of time.
SPECIFICATIONS
Power input............................................................................................. AC 230V~ 50Hz
Fuse ............ ................................................................................................6.3A/250V
Max overall electric current:...........................................................................20AMP/5000W
Current per channel :......................................................................................6AMP/1500W
Weight..................................................................................................................2.4kg
Dimensions ....................................................................................L482 x W95 x H 135mm
I
G
H
T
S
W
I
T
I
G
H
T
S
W
I
T
GB - USER MANUAL
LC-1006F
10 light flash button
C
H
C
O
N
T
R
C
H
C
O
N
T
R
(15-1175)
10 outlets
O
L
L
E
R
O
L
L
E
R
A fuse in per channel
