X4-TECH DOGBOX User Manual page 6

10
12
11
13
10
16
15
Funktionen | Functions | Functies | Fonctions | Funzioni
LED Lichtkreis | LED light circle | LED-lichtkring |
10.
Circuit d'éclairage LED | Anello luminoso a LED
Kopfhöreranschluss | Headphone jack | Koptelefoonaans-
11.
luiting | Connexion casque | Connessione per auricolari
Betriebs-Indikator LED | Operation indicator LED |
12.
Werkingsindicatie LED | LED de fonctionnement | Spia di
funzionamento a LED
Line-In Anschluss | Line-in socket | Line-In aansluiting |
13.
Connexion Line-In | Connessione Line-In
14
Akku-Ladeanzeige LED | Charging LED | Baterij laadindi-
14.
cator LED | Indicateur de chargement | Indicatore di carica
della batteria
micro-USB Anschluss | micro-USB socket | Micro-USB
15.
Aansluiting | Connexion micro-USB | Connessione
micro-USB
SD-Kartenslot | SD card slot | SD-kaartgleuf | Fente pour
16.
carte SD | Slot per schede SD
11
