TOOLS AND MATERIALS Plug: ·1/2" copper tubing ·Assorted copper fittings; G3/8", G1/2" and G3/4" copper unions ·Wire Cutters or Wire Strippers ·Conventional woodworking tools and materials ·45 and 90 degree elbows ·Support Blocks (heat resistant) Hacksaw or Drill w/ 1-1/4" & Sealant Tape Propane Torch Tube Cutter...
Page 3
Follow all local plumbing and electrical codes. All electrical work should be done by a qualified electrician. Disconnect all power before making any electrical connections. Kohler Co. reserves the right to make revisions in the design of products without notice, as specified in the Price book. SAVE THESE INSTRUCTIONS.
Page 4
That thermostat sensors shall be installed so that they are not influenced by incoming air. 4. Install the Electrical Supply Model K-5525T-XT-NA K-5526T-XT-NA K-5529T-XT-NA K-5531T-XT-NA K-50205T-XT-NA Generator - Dedicated 5.95 kW, 220-240V~ 7.93 kW, 220-240V~ 9.92 kW, 220-240V~ 10.13 kW, 220-240V~ 3.28 kW, 220-240V~,...
Page 5
NOTICE: Each steam generator requires a dedicated circuit. DANGER: Risk of electrocution. Disconnect the electricity to the working area at the main breaker panel before performing these installation steps. Follow all local electrical codes. All electrical work should be done by a qualified electrician. ...
Page 6
Install copper union as close Shut-Off Water Feed to Steam Install copper union Valve as possible to steam generator. Generator (Pipe of Hose) in water feed line Steam Head Nipple Outlet (1/2" NPT(F) Nipple Pipe to G 1/2"(M)) (3/8" NPT(F) to Nipple Steam G 1/2"(M)) Recommended In-Line...
Page 7
Install the Water Supply Line to the Generator NOTE: For all NPT threaded connections, use pipe tape or pipe sealant. Do not overtighten the fittings. Connect to an existing cold water line, and run a 1/2" cold water line to a shut-off valve before the in-line ...
Page 8
NOTICE: The steam generator is not have a separate power supply. The power circuit breaker that meets the specifications for each steam generator should be installed. NOTICE: hardwired must be protected with heat insulating sleeve of an appropriate temperature rating. Model K-5531T-XT-NA K-50205T-XT-NA K-5525T-XT-NA K-5526T-XT-NA K-5529T-XT-NA 3.28 kW, 5.95 kW, 10.13 kW,...
Page 9
Complete the Installation Install the steam housing and steam head following the Steam Control Kit instructions. Install the steam control following the Steam Control Kit instructions. B. STEAM CONTROL KIT INSTALLATION Temporary Nipple Mark the nipple even with finished wall. Provide clearance from wall.
Page 10
Wall G 1/2" Elbow Apply thread sealant Steaming Housing Aromatherapy Steam head Nipple Well Steaming Apply thread sealant Housing Steam Nipple Steam head (1/2" NPT(M) to G 1/2"(F)) 2. Install the Steam Head(s) NOTICE: Do not obstruct the steam head with shut-off valves, plugs, or caps. Subtract 3.2cm from the marked length to determine the appropriate nipple size.
Page 11
3.2cm D Hole Finished Wall Apply Mounting Plate Sealant Screw Anchor Apply Sealant 150cm to Floor Remove Tool 3. Install the Steam Control WARNING: Risk of personal injury. Do not install the Steam Control User Interface outside the steam enclosure. The User Interface must be installed within the enclosure to allow the sensors to regulate the temperature and control the flow of steam.
Page 12
UIC IoT (IoT) 2PIN 2PIN 4PIN WI-FI/BLE Module Power Y-CABLE 4 Wall Adaptor (100 mm) Install Wi-Fi/BLE module and power adapteror After double-sided tape in bottom side of power adapter, remove the adhesive backing and mount the firmly to the wall. Don't attached power adapter to the steam generator. After double-sided tape in bottom side of Wi-Fi/BLE module, remove the adhesive backing and mount the ...
Page 13
Display Timer Temperature Clock On/Off Decrease Increase C. OPERATE THE STEAM CONTROL Steam Control Operation NOTE: The clock is always displayed on the display when the steam is not in use. Push the "On/Off" button to start the steam. When the button is pushed the white light on the "On/Off" button turns on. It remains on until the unit is turned off.
CARE AND CLEANING For best results, keep the following in mind when caring for your KOHLER product: Always test your cleaning solution on an inconspicuous area before applying to the entire surface. Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and dry any overspray that lands on nearby surfaces.
TROUBLESHOOTING GUIDE CAUTION: Troubleshooting steps involving internal wires or electrical components should be performed by a qualified electrician. NOTE: This troubleshooting only applies to the steam generator. For issues involving the steam control, consult the troubleshooting guide provided with the Steam Control Kit documentation. The troubleshooting guide is for general aid only.
Page 16
Error 1, 2, 3, 4, 7, or 8 is A. A button on the user interface is A. Turn off power to generator and attempt to free stuck buttons. displayed. stuck. Restore power to generator. B. The user interface is damaged. B.
Page 17
No steam after 5 minutes A. An error has occurred. A. Check the User Interface for error of pressing power. messages. If an error message appears, see the appropriate error message troubleshooting. B. The temperature setpoint has already B. Confirm the temperature setpoint is been reached.
