- Page 1 User Manual LG-3X1BYOD-P HDMI 2.0 3x1 Multi-format Presentation Switcher All Rights Reserved Version: LG-3X1BYOD-P_2019V1.0 www.logicav.in...
-
Page 2: Safety Precaution
Refer all servicing to qualified service personnel. After-sales Service We provide limited warranty for the product within three years. Packing List 1x LG-3X1BYOD-P 1x User Manual Note: Please contact your distributor immediately if any damage or defect in the components is found. -
Page 3: Product Introduction
The LG-3X1BYOD-P is an HDMI 2.0 3x1 Multi-format Presentation Switcher converting AV signal from HDMI, Mini DP and USB-C inputs to HDMI output. The LG-3X1BYOD-P is a green low energy consumption product which has a various application in different places, such as classroom, small meeting room, lecture hall, and etc. -
Page 4: System Connection
HDMI 2.0 3x1 Multi-format Presentation Switcher ③ Type-C USB input port to connect MacBook, Chromebook or other devices with SlimPort output. ④ The power LED illuminates blue when power is applied and is off when no power is present. ⑤ Type-A HDMI output port to connect display. ⑥... -
Page 5: Specification
HDMI 2.0 3x1 Multi-format Presentation Switcher Specification Input Connector Type (1) Type-A HDMI, (1) Mini DP, (1) Type-C USB HDMI Video Resolution Up to 4K@60Hz 4:4:4, HDR Mini DP Video Resolution Up to 4K@60Hz 4:4:4 USB-C Video Resolution Up to 4K@60Hz 4:4:4 LPCM 7.1 audio, Dolby Atmos®, Dolby®TrueHD, Dolby Digital®...
