TDR Eco Pro Manual

Initial Setup
Unpacking the machine
1. Open box and lift out machine ne 2 Carefully remove contents 2. Carefully remove contents
Please keep packaging in case the machine needs to
be returned at any point.
Contents
The contents of the box is listed on the back of this
sheet. Please check to make sure that the contents
are complete. If you have any queries with the
content please contact Technical Support, Monday to
Friday, 9am to 5pm on:
0800 412 5424
Setting up your machine
Your Eco Pro is designed so that you can set it up
quickly and start using it right away. Here are
the key tasks to complete before you turn on your
machine:
Locating the machine
Place the machine on a machine on a
sturdy, fl at surface near at surface near
a power socket. socket.
Attaching the bottle holder
Start by removing the thumbscrew on the back of the
machine. Locate the two hooks on the bottle holder
into the slots on the back of the machine, slide the
bottle holder to the left and then use the thumbscrew
to secure the bottle holder in place.
Installing the polish and water
1. Remove the caps from the two bottles and store.
2. Hang the polish bottle on to the left slot on the
bottle holder (looking at it from the back).
3. Hang the water solution bottle on to the right slot
on the bottle holder.
4. The cap with the green text attaches to the polish
bottle, but you must remove the small black
rubber cap from the pipe fi rst.
5. The cap with the blue text attaches to the water
solution bottle.
5. Ensure that the tubes reach the bottom of both
bottles.
Polish
Removing the polish nozzle caps
There are two more black rubber caps on the polish
nozzles, inside the machine, that must be removed
before using the machine. It is not necessary to
keep these as they are only designed to prevent the
polish from drying out in storage
Nozzle
cap 1
Nozzle
cap 2
Installing the chip
Locate the chip card
and install as shown
here
Powering up the machine
Once you have set up your machine you are ready
* The slots are
to repair your fi rst disc. Plug the machine into a
different sizes
grounded power outlet and switch on the mains
and cannot be
confused.
socket switch. Then switch the machine on using the
red power switch on the front of the machine.
Water
The machine will bleep and the lid will open
solution
automatically.
Now refer to the user guide in the information pack
for instructions on repairing your fi rst disc.
