- Page 1 3-Axis Stabilized Handheld Gimbal for Smartphone Instructions EN V 1.0...
-
Page 2: Table Of Contents
Catalogue 1. Overview 2. Start to Use 2.1 Charging 2.2 Positioning Lock 2.3 Smartphone Installation 2.4 Balancing 2.5 Power ON / OFF 3. Function Operation 3.1 Function / Modes Introduction 3.2 Joystick 3.3 Function Button Operation 3.4 Shutter Button Operation 3.5 Focus Button Operation 3.6 Trigger Button Operation 3.7 Light Indicator Explanation... - Page 3 Vimble 2S is a three-axis handheld gimbal suitable for mobile phones with joystick, Bluetooth shutter, position lock, extendable bar, etc. The gimbal can stabilize the smartphone intelligently. The gimbal supports landscape and portrait shooting, which can also control phone shooting. Connect with Feiyu ON App to achieve...
-
Page 4: Overview
1. Overview *This product does not include the smartphone Micro USB Port for Smartphone Charging Tilt Axis Cross Arm Roll Axis Tilt Axis Lock Smartphone Holder Vertical Arm Pan Axis Function Button Micro USB Port Roll Axis Lock Handle (Built-in battery) Extendable Bar Extendable Range 0~183mm... -
Page 5: Start To Use
2. Start to Use TIPS (1) Please fully charge the battery before powering on the gimbal for the first time. (2) If the power is too low, the red light will flash three times every five seconds that indicating you should charge it immediately. (3) When not in use, power off... -
Page 6: Smartphone Installation
2.3 Smartphone Installation Place smartphone in holder so that the phone is snug against the back of the holder. It's recommended to remove your smartphone protective case. Smartphone holder width range : 57-84mm. 2.4 Balancing (Balancing before power on) If the smartphone tilts to left or right after installed the smartphone, please slide the cross arm to the opposite direction which the smartphone tilts to to balance. -
Page 7: Power On / Off
2.5 Power ON / OFF Make sure unlock the roll and pan lock before powering on the gimbal. Power ON Long press the function button and release it when you hear the tone. （Green light will change to blue） Long press the function button and release it when you hear the tone. Power OFF （The red light will turn off）... -
Page 8: Joystick
Lock the tilt Follow and position rotate Follow and Follow and Lock the pan rotate rotate position Pan Mode Lock Mode Follow Mode Default mode 3.2 Joystick Upward Move to left Move to right Downward 3.3 Function Button Operation Function Function button Pan Mode... -
Page 9: Shutter Button Operation
（1）Power on the gimbal, open smartphone bluetooth. （2）Choose below Bluetooth connection way: a. Choose Vimble 2S Bluetooth to connect like FY_Vimble2S_xx. b. Open Feiyu ON app, logon or register via tips to connect. （3）After Bluetooth connecting successful, the shutter button is activated. -
Page 10: Focus Button Operation
3.5 Focus Button Operation Focus Button Function Sliding up-down Adjust focus (Adjust field-of-view) Used with Feiyu ON App 3.6 Trigger Button Operation Trigger Function Button Enter follow mode Long press （Release trigger button enter into previous mode） Double tap Reset The button's operation function can be modified on App, after connecting Feiyu ON App succeeded. -
Page 11: Trigger Button Operation
3.8 Trigger Button Operation Manually move camera to desired position,and hold for half a second, new tilt position is automatically saved. 3.9 Landscape and Portrait Shot Switching Payload in Press buttons to switch portrait mode Effected only when tilt axis on right side. Hold the gimbal horizontally, press and hold the trigger button, and then single tag function button to switch between landscape and portrait mode. -
Page 12: Gimbal Initialization
3.10 Gimbal Initialization Initialize gimbal when: Smartphone fails to remain level. Gimbal has no been used for a long period of time. Gimbal is used in extreme temperature variations. STEP Click the function button five times. The motors will stop working. Status indicatorturns solid blue. -
Page 13: Smartphone Charging
3.11 Smartphone Charging Charge the smartphone via cable and choose the corresponding cable according to charging port. Micro USB Port Cables www.feiyu-tech.cn... -
Page 14: Connect And Use Feiyu On App
4. Connect and Use Feiyu ON App 4.1 Download the App Feiyu ON Timer Photo/Video Zooming Path time-lapse photography Overlapping Light tracking Object tracking Face locking photography images Ultra-wide angle Free panoramic Filter Beauty panorama Firmware ..Video editing Slow motion upgrade Scan the QR code to download the app, or search for "Feiyu ON"... -
Page 15: Shooting / Control Interface
4.3 Shooting / control interface Shooting interface Control interface Face/object Setting - Advanced tracking Upgrade settings Back Tutorial Remote Control Album Gimbal information FY_PocketV_xx Reset Virtual Joystick Switch between Camera setting photo/ recording mode Choose photo Shutter Switch between Lock mode Panning mode modes front and rear camera... -
Page 16: Specifications
5. Specifications 118 mm 110.5mm Max. Tilting Range 320° Max. Tilting Range 320° Max. Panning Range 320° Operation Time 12 Hours Weight 272g (Not including the smartphone) Payload 210g (After balanced) Adapter smartphones iPhone and Android phones (Width range 57-84mm) www.feiyu-tech.cn... - Page 17 Disclaimer Thanks for using Feiyu Gimbal. The information in this document affects your safety and your legal rights and responsibilities. Read the entire document carefully to ensure proper configuration before use, Failure to read and follow instructions and warnings in this document may result in serious injury to yourself or others, or damage to your products or damage to other objects in the vicinity.
- Page 18 Official Social Media Website Facebook Youtube Twitter Instagram Facebook: www.facebook.com/feiyutech YouTube Channel: www.youtube.com/c/Feiyu-tech Twitter: www.twitter.com/feiyutech Instagram: www.instagram.com/FeiyuTech YouTube Channel: www.youtube.com/c/Feiyu-tech Online Store: store.feiyu-tech.com...
- Page 19 Guilin Feiyu Technology Incorporated Company For more information, please visit our official website www.feiyu-tech.com E-mail: service@feiyu-tech.com Tel: +86 773 2320865 Due to software and hardware improvements, your actual product might differ from the descriptions and pictures in this user manual. You can get the latest user manual from the official website.
