- Page 1 USER’S MANUAL...
-
Page 2: Table Of Contents
English CONTENTS 1. GUIDE ......................2 1.1 IMPORTANT SAFETY INSTRUCTIONS ..................2 1.2 UNPACKING ..........................2 1.3 PRODUCT OVERVIEW& ILLUSTRATION ................3 1.4 INSTALLATION OF METER .......................4 2. OUTLINE ......................5 3. THE MENU OSD INSTRUCTION ..............6 3.1 DVB-S2 ............................6 3.2 DVB-T2 ............................9 3.3 DVB-C ............................10 3.4 SPECTRUM ........................... -
Page 3: Guide
1. GUIDE 1.1 IMPORTANT SAFETY INSTRUCTIONS Thank you for choosing our product. Before installation, we would like to remind you some notes, which is very important for operating safely and properly, as follows: • Be sure to read this user manual before starting your operation. • You must install the dish with correct direction and angle. -
Page 4: Product Overview& Illustration
Speaker integrated Power Power indicator light Vertical /Horizontal polarization voltage output light 22kHz 22kHz indicator light LOCK Signal lock indicator light Antenna power key CHG (Note1) Charger indicator light 20 AV-S AV IN/OUT switch key Auxiliary function key 22 F2... -
Page 5: Installation Of Meter
Description FUNCTION 25 Red & TTXT Red KEY &Teletext interface 26 Green & SUBT Green key & Subtitle interface 27 Orange &TV/R Orange key & TV and radio switch 28 BLUE &AUDIO Blue key & Audio interface Volume Control or move cursor, channel or change, 29 NEVIGATION KEY confirm etc Show the main menu on the screen or jump back to... -
Page 6: Outline
• 7 Inch High Definition TFT LCD Screen • Fully DVB-S/S2/T/T2/C, MPEG-2/MPEG-4 compliant • MPEG-2 / H.264 / H.265Hardware decoding • Digital meter for signal strength and quality • Constellation analyzer • Spectrum analyzer • Supports scan of Auto,Blind, Manual or NIT • Sound and Light Alarm for Locking Signal... -
Page 7: The Menu Osd Instruction
3. THE MENU OSD INSTRUCTION If you have installed and connected the cables to the receiver, pressing MENU to display the Main Menu. • DVB-S2 • DVB-T2 • DVB-C • Spectrum • Loop Search • Others • Multimedia • System Setting Press the keys of YZA B to move the cursor up or down in the menu interface, then use OK to confirm a selection. - Page 8 English 3.1.2 LNB TYPE There are 4 types you can select: C Band/Ku Band/Unicable/DCSS. 3.1.3 LNB FREQUENCY Press AB key to switch LNB frequency you want. 3.1.4 TRANSPONDER Press AB key into the TP list. Use YZ key to move the cursor then press OK to select the TP you want.
- Page 9 3.1.13 QUICK SEARCH When parameters have been set done, press OK into quick search. There will have some signal information displayed on the screen. • Scan: Press the red key to search the current TP. • Auto Scan: Press the green key to auto blind...
-
Page 10: Dvb-T2
English • S/Q: Press the orange key to enlarge showing of the signal strength and quality. • Constellation: Press the blue key into the constellation. 3.2 DVB-T2 Select DVB-T2, then press OK into the Scan Setup. 3.2.1 COUNTRY Press AB key to change the default country. -
Page 11: Dvb-C
• Scan: Press OK or red key to search current channel. • Auto Scan: Press green key to auto search the current channel. • S/Q: Press blue key to enlarge showing of the signal strength and quality. 3.3 DVB-C Select DVB-C, then press OK into the Scan Setup. -
Page 12: Spectrum
English 3.3.2 CHANNEL NO. Press AB key to change the channel number. 3.3.3 FREQUENCY Frequency of the current channel, input the value by using the number keys. 3.3.4 STANDARD Press AB key to select J83.A/C or J83.B. 3.3.5 BEEP TONE Press A B key to switch beep tone. -
Page 13: Loop Search
• Locked: Press orange key to lock all the current frequency points, and remain unchanged unless you press again. • Scan : When the frequency points have been locked, you can press blue key to receive signal on a point. 3.4.3 CABLE-SPECTRUM Please refer to 3.4.2. - Page 14 English 3.6.1 CHANNEL LIST • SAT Press F1 key to switch different channel list. • Lock Press YZ key to select programs we want to lock, then press the red key to lock them. • Del Press the green key to delete current channel. • Move Select a channel first, then press the orange key to move to other position.
- Page 15 Press the green key to edit current satellite. Press the orange key to delete current satellite. Press the blue key to scan current satellite. 3.6.4 TRANSPONDER LIST All the transponders under the current satellite will be displayed on the screen, and press A B key to switch satellite.
- Page 16 English Press the green key to edit current transponder. Press the green key to delete current transponder. Press the blue key to scan current transponder. 3.6.5 MOTOR SETTING There are 5 modes in motor setting: • USALS Controling motor according to your local position, you can modify it in Angle Calculation.
-
Page 17: System Setting
3.6.6 ANGLE CALCULATION Input satellite longitude, local longitude and latitude by number key, and device will calculate the polarization angle, azimuth and elevation on the top of the screen. Press the red key to calibrate. 3.6.7 OPTICAL POWER Please connect optical port, then we can test the optical power by selecting the wave length and PWR unit.The test result will display in the middle of the screen. - Page 18 English Press AB key to change the aspect ratio: 4:3/16:9/full screen. • Video Resolution Press AB key to change the video output resolution: 720p/1080i/1080p. • HDMI Audio Press AB key to change the digital audio output format: PCM/RAW/MUTE. • Time Zone Press AB key to change the Time Zone.
-
Page 19: Technical Specification
4. TECHNICAL SPECIFICATION TRANSMISSION STANDARDS DVB-S2/S, DVBT/T2, DVB-C SATELLITE INPUT/DEMODULATION Connector Type F Type Input Frequency 950 to 2150 MHz Signal Input Level - 65 to -25 dBm Band Switch Control 22KHz LNB Supply 13V/18V, IMax 400mA Demodulation Type QPSK,8PSK,16APSK Symbol Rate 2<Rs<45Mband(SCPC/MCPC) - Page 20 English Resolving rate PAL-25 frame@720*576,NTSC-30 frame@720*480 Signal compatibility Support conversion for different video formats Video Format 4:3,16:9,By Pan & Scan and Letter Box conversion Audio Decompression MPEG-1 Layer I/II, MPEG-2 Layer I/II Audio Output Mode Stereo, Mono,R/L DATA SERVICE PORT...
-
Page 21: Trouble Shooting
ON. The satellite dish is not Adjust the dish. Check the No sound or picture pointing at the satellite. Signal Level in the Antenna Setup Menu Check the cable connections. LNB and other equipment No signal or weak signal... - Page 22 USER’S MANUAL...
