Thank you for choosing WELL. Please read carefully the following instructions and keep
them within reach.
SPECIFICATIONS
Diameter: 43 cm
Power: 45 W
Voltage: 230V~ 50 Hz
3 speed : 950RPM- 1100RPM- 1250RPM
Color: black
Cross base: 60* 60 cm
Height: 1.1M- 1.3M adjustable
Oscillation: 90°
Noisy level: <65 dB
Mesh grill
IP20
Always unplug the appliance before any cleaning or maintenence operation and accesories
assembly.
CAUTION: If the electric cable is damaged, it must be replaced by the manufacturer, his
after-sales service or people with similar qualification, in order to avoid any danger. In order
to minimize the risk of electric shock, in the event of breakedown, not to openthe case but
to call upon a qualified technician for repairs.
The item must not be left unattended when it is connected to main supply.
The item is not to be used, if it has been dropped or if there are visible signs of
damage.
This appliance is only intended for household use
SPECIAL WARNING FOR THIS DEVICE
• Do not carry the unit by holding the power cord.
• Do not insert objects through the protective grill.
• Do not use the device in a bathroom
• Always use the fan with the included foot and upright.
Warning ! Never use without the guards in place. After assembly, do not remove the guards
for maintenance purpose or cleaning.
UseR'S MANUAL
Model: FAN-STAND-FREEZE-WL
Advertisement
Table of Contents
Related Manuals for Well FAN-STAND-FREEZE-WL
Summary of Contents for Well FAN-STAND-FREEZE-WL
- Page 1 USER’S MANUAL Model: FAN-STAND-FREEZE-WL Thank you for choosing WELL. Please read carefully the following instructions and keep them within reach. SPECIFICATIONS Diameter: 43 cm Power: 45 W Voltage: 230V~ 50 Hz 3 speed : 950RPM- 1100RPM- 1250RPM Color: black Cross base: 60* 60 cm Height: 1.1M- 1.3M adjustable...
- Page 2 USER’S MANUAL Model: FAN-STAND-FREEZE-WL TO KNOW IT’S UNIT 1. Front Guard 2. Fan Blade 3. Blade Nut and Screw 4. Rear Guard 5. Motor axis 6. Motor Housing 7. Oscillation Control 8. Control panel 9. Body 10. Pivot safety Screw 11.
- Page 3 USER’S MANUAL Model: FAN-STAND-FREEZE-WL ASSEMBLING Take the two base cross and push the end caps into the ends. Cross them over together as draw. Remove the four screws from the base and pole the below tube & base to the base.
- Page 4 USER’S MANUAL Model: FAN-STAND-FREEZE-WL Unroll the power cord completely. Check that the tension in force in the country where you are correspondes to that indicateed on the apparatus. Connect the apparatus in a correct socket outlet, and connected to the ground.
- Page 5 USER’S MANUAL Model: FAN-STAND-FREEZE-WL M/ VITESSE (Speed/ON) Press the “M/Vitesse” button to turn the fan on. When the fan is turned on it will start at the speed setting. Select the desired speed by pressing the “M/Vitesse” (ON / Speed) button...
- Page 6 USER’S MANUAL Model: FAN-STAND-FREEZE-WL CLEANING AND MAINTENANCE Before cleaning: always switch off the appliance, disconnect the apparatus and let it cool. Clean the outside of the apparatus with a sponge or slighty wet linen. Do not use abrasive cleaners, gritting, or metal brush or another cutting object. The greasy dirt of the fan fuselage and fan blade should be cleaned so as not change its colour or be damaged.
