- Page 1 MANUAL OPERATING & MAINTENANCE INSTRUCTIONS GETINGE GS 100 GETINGE GS 200 geprüfte Sicherheit IMPORTANT!: Read these instructions carefully and familiarize yourself with them before the unit is put into service. GS100200-GB-007.doc 04-99...
-
Page 2: Table Of Contents
TABLE OF CONTENTS HOW TO USE THIS MANUAL........................2 INSTALLATION .............................3 START-UP..............................3 HOW TO USE THE SEALER.........................4 HOW TO USE THE SEALER WITH ROLL-SUPPORT AND CUTTING DEVICE: ........5 EXCHANGING THE CUTTING-KNIFE......................6 TROUBLESHOOTING ...........................7 TECHNICAL SPECIFICATIONS: ........................7 SPARE PART LIST............................8 APPENDIX ..............................9 HOW TO USE THIS MANUAL This manual explains how you should install the sealer, how it should be operated and what you can do when problems should occur. -
Page 3: Installation
INSTALLATION The environment for the sealer should be clean and dust-free. . After unpacking the sealer, place it at the desired position. This should be a flat and firm surface. . Make sure, the voltage and frequency match those specified for the sealer. (Important for warranty cases). -
Page 4: How To Use The Sealer
HOW TO USE THE SEALER Put the adjust-knob “sealing time” to "0" (fig. 1). By turning the adjust-knob clockwise the sealing-time can be adjusted. Advise: Increase the sealing-time in small amount starting from "0". Place the material to be sealed between the sealing-bars. Make sure, the paper- material is below and the foil-material is on top. -
Page 5: How To Use The Sealer With Roll-Support And Cutting Device
HOW TO USE THE SEALER WITH ROLL-SUPPORT AND CUTTING DEVICE: Sealing roll-material should be done as follows; Place the roll-material on the roll-support. Pull the material according to fig. 2 up to the sealing-bars. The foils-material “F” is on top, the paper “P” below. The cutting-knife should be on the left or right side on the upper bar. -
Page 6: Exchanging The Cutting-Knife
To make sure, your sealer always produces a good quality seal, we advise you to check the sealing result at least once every week. Important: To make sure, your sealer has a long and trouble less life, we advise you to service your sealer at least two times every year. -
Page 7: Troubleshooting
TROUBLESHOOTING It could be possible, your sealer does not function as it should. Attention! The impulse-sealer should be disconnected from the mains before opening the housing. Servicing and repairs should only be done by the dealer or by sufficient technical schooled employees. In any case, the sealer should be disconnected from the mains. -
Page 8: Spare Part List
SPARE PART LIST POS.NR Description Ident. No. Knife holder 4425121 PTFE-tape 4413053 PTFE-strip 4413054 Cutting-knife 4413008 Seal-wire 4425239 Pressure-strip 4413072 Potentiometer 4414002 Adjustment knob 4414204 switch 4414021 Electronic-plate 4425236 Transformer 4414223 * Only sealer with cutting device For other parts, please contact your dealer 04-99 GS100200-GB-007.doc... -
Page 9: Appendix
APPENDIX GS100200-GB-007.doc 04-99... - Page 10 04-99 GS100200-GB-007.doc...
- Page 11 Picture 1 Picture 3 Picture 2 GS100200-GB-007.doc 04-99...
