The new MPL-1000 PLUS is designed to meet today's laundry chemical injection needs with economy and greater
flexibility in mind. Through advanced microprocessor technology, the MPL-1000 PLUS is one of Knight Equipment's
least expensive laundry injectors, yet has all of the required features to meet every type of washroom condition. The
MPL-1000 PLUS can run up to 6 pump outputs in any one of three different modes; SIGNAL, SEQUENCE, and
RELAY mode. L.E.D indicators let the user know whether they are programming in SIGNAL or SEQUENCE mode,
what is being programmed, the mode the MPL-1000 PLUS is running in, and which pump is being signaled. The
MPL-1000 PLUS has dual formula capability for light or heavy soil conditions for each pump, with separately
programmable delay times for each formula. Innovative use of delay times allows calibration to be a one-man job. All
programmed times are stored in a non-volatile memory which cannot be altered by voltage spikes or power outages.
All signal inputs have independent signal and common connections, allowing multi-washer connections to one circuit
board. The signal input circuitry will accept and verify a signal anywhere between 18 to 240 volts (AC or DC).
When connecting signal wires to the MPL-1000 PLUS, always check the schematic of the washmachine. If in doubt
about the installation, please contact your nearest authorized Knight representative or contact the machine
manufacturer at the number listed below.
MACHINE
DESCRIPTION
American
Amer. Laundry Machinery
Braun
G.A. Braun, Inc.
Cascadex
Amer. Laundry Machinery
Cook
Cook Machinery Co.
Dyna Wash
Edro Corporation
Hammond
Washmaster Systems
Huebsch
McGraw Edison Co.
Inn House
Wascomat of America
Milnor
Pellerin Milnor Corp.
Schulthess
Schulthess Machinery
Speed Queen
Ametek
Troy
Ametek
Uniwash
Unimac Company
Washex
Washex Machinery Co.
Wascomat
Wascomat of America
Zanussi
Zanussi Corporation
VOLTAGE INFORMATION
Main input power voltages are determined by use of "jumpers" near the power transformer:
For 120v AC, jumpers are placed on JP17 and JP19 only.
For 240v AC, jumpers are placed on JP18 and "Spare Jumper" only.
Be sure that this voltage matches the intended main power voltage. The voltage selected by the jumpers MUST
MATCH the pump motor voltage and should NOT BE TOUCHED if the MPL-1000 PLUS is received as a new item.
0900820 (draft 04/00)
CITY/STATE
Cincinnati, OH
Syracuse, NY
Cincinnati, OH
Dallas, TX
E. Berlin, CT
Memphis, TN
Cincinnati, OH
Inwood, NY
Kenner, LA
Bethesda, MD
Grand Prarie, TX
Grand Prarie, TX
Marianna, FL
Wichita Falls, TX
Inwood, NY
New York, NY
PHONE
(503) 731-5500
(315) 475-3123
(503) 731-5500
(214) 421-2153
(203) 828-0311
(901) 362-0023
(503) 351-6510
(516) 371-4400
(504) 467-9591
(301) 656-9308
(214) 647-2626
(214) 647-2626
(904) 526-3405
(817) 855-3990
(516) 371-4400
(212) 532-5494
Page 1 of 8
Advertisement
Table of Contents
Summary of Contents for Index KNIGHT MPL-1000 PLUS
- Page 1 The new MPL-1000 PLUS is designed to meet today’s laundry chemical injection needs with economy and greater flexibility in mind. Through advanced microprocessor technology, the MPL-1000 PLUS is one of Knight Equipment’s least expensive laundry injectors, yet has all of the required features to meet every type of washroom condition. The MPL-1000 PLUS can run up to 6 pump outputs in any one of three different modes;...
- Page 2 SIGNAL MODE OPERATION In signal mode operation, signals received for each pump activate programmed run and delay times for that pump. To select signal mode, move the MODE SELECT jumper located above the RELAY, SINGL, and SEQ. L.E.D.’s to the jumper terminals located above the SIGNL MODE L.E.D. (JP4). •...
- Page 3 (6) If an alternate formula is to be used, move the black slide switch to the position of the formula to be used, and repeat steps #3 and #4. (7) When finished programming the pumps, move the slide switch back to the formula #1 position. •...
- Page 4 [METHOD 2: USING THE UP/DOWN BUTTONS TO SELECT TIME] DO NOT apply a signal when programming Delay Times using Method 2 in Sequence Mode. (1) Depress and release the “MODE SELECT” button until “DELAY TIME” L.E.D. is lit. (2) Depress the UP button for 1 second and release. (3) Depress and release the PROGRAM/PRIME switch of the pump # to be programmed.
-
Page 5: Priming The Pumps
(4) Adjust the programming for pump #6 for the amount of time that the flush manifold will flush with water AFTER chemical has been injected. The manifold will always flush with water WHILE chemical is being injected. (5) During operation, the flush manifold will flush each time chemical is injected into the machine. During flush, if the flow switch connected to the FLUSH terminals is not closed (or the terminals are not jumped), a “flush error”... -
Page 6: Pre-Installation
(1) Using the “BLEACH DEFEAT” jumper located on the lower left corner of the circuit board, select the pump which is dispensing bleach. Only pumps 2, 3, or 4 can be used for bleach defeat. (2) Connect the black and white wires from the RSB-1000 to the connections marked “SWITCH CON/NO VOLTAGE - BLEACH DEFEAT”. -
Page 7: Injector Installation
INJECTOR INSTALLATION (1) Remove the locking cover panel from the injector system using the key provided. (2) Mount the injector in a convenient location on a wall near the supply containers. This location is usually near the laundry machine; however, it can be mounted as a remote pumping system. It is recommended that the injector be mounted within 50 feet of the laundry machine. -
Page 8: Warranty
DISCLAIMER Knight Inc. does not accept responsibility for the mishandling, misuse, or non-performance of the described items when used for purposes other than those specified in the instructions. For hazardous materials information consult label, MSDS, or Knight Inc. WARRANTY All Knight controls and pump systems are warranted against defects in material and workmanship for a period of ONE year.
