- Page 1 HDX50-IR HDMI Extender over single 50m UTP Cables with IR Control User manual VER:1.1 HELPLINE 0861 40 41 42 • www.spacetv.co.za...
- Page 2 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1. INTRODUCTION The HDMI Extender over Single Cat5e/6 with IR extends high definition video and audio signals and IR, at a distance of up to 164ft/50m over a single Cat5e/6 cable.
- Page 3 The extender includes two units: transmitting unit and receiving unit. The transmitting unit is used to capture the HDMI input with IR signals and carries the signals via one cost effective Cat5e/6 cable. The receiving unit is responsible for equalizing the transmitted HDMI signal and reconstructing IR control signals.
-
Page 4: Specifications
3. FEATURES • Allows HDMI Audio/Video and IR signals to be transmitted over a single Cat5e/6 cable. • Support copy EDID from receiver display or loop out display. • Allows for cascading via additional HDMI loop out port. • Support Power over cable function. • Transmission Range: Extends 1080p resolution up to 50m over a single Cat5e or Cat6 cable. • Works with HDMI and HDCP compliant devices. • Supports up to 1080p High Definition resolution. • Compact design for an easy and flexible installation. 4. SPECIFICATIONS Video Bandwidth: Single-link 165Mhz [ 4.95Gbps] Video Support: 480i/480p/720p/1080i/1080p @60 Audio Support:... -
Page 5: Mechanical Specs
RJ-45 connector: WE/SS 8P8C 3.5mm connector: (TX and RX) IR Receiver/IR Blaster MECHANICAL SPECS Housing: Metal enclosure Power Supply: (1) 5V1A DC Power consumption: 1.5 watts (TX); 1.0 watts (RX) Operation temp.: 32~104 °F Storage temp.: -4 ~140 °F Relative humidity: 20~90 % RH (no condensation) 5. PANEL DESCRIPTIONS 5.1 Transmitting unit 1. HDMI in: This slot is where you connect the HDMI output port of your source equipment such as DVD/ Blu-ray players or Set-Top-Box with an HDMI cable. - Page 6 2. EDID: The switcher can switch copy EDID function,switch to right position,the extender will copy hdmi loop out display EDID information to source. Switch to left position,the extender will copy Receiver display EDID to source. 3. HDMI out: This slot is to connect the HDMI input of your display such as an HDTV.
- Page 7 5.2 Receiver unit 1. EQ switcher: HDMI Receiver equalizer switcher. 2. HDMI out: This slot is to connect the HDMI input port of your display such as an HDTV. 3. IR in: Connect to the IR Receiver for IR signal reception. Ensure that remote being used is within the direct line- of-sight of the IR receiver.
- Page 8 5.3 RX Equalizer distance adjust If you see flickering or blinking image on the display, adjust the EQ switch to improve the cable skew. MAX stands for the strongest HDMI signal level for the longest possible transmission length while MIN stands for the weakest HDMI signal level for short transmission length. Adjust the signal level from MIN to MAX until desired video quality is displayed.
-
Page 9: Connection Diagram
6. CONNECTION DIAGRAM IR TX HDTV HDMI SOURCE HDTV HELPLINE 0861 40 41 42 • www.spacetv.co.za... -
Page 10: Connect And Operate
7. CONNECT AND OPERATE 1. Connect a source such as a Blu-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc. to the HDMI input on the Transmitting unit. 2. Connect a display such as an HDTV or HD Projector to the HDMI output on the Receiving unit. - Page 11 and adjust the resolution (lowest to highest until signal is displayed). A 24 Hz vertical refresh rate may work better than 60 Hz or higher. Use the source remote at the receiver emitter to test IR functionality. If the IR remote function is not responding, check the emitters to ensure they are placed correctly and are plugged into the correct IR jacks on the Extender set receiving and transmitting units.
- Page 12 IR RECEIVER (RX) To control the source: Plug IR Receiver into IR RX port of receiver unit; place receiver at or near display. HELPLINE 0861 40 41 42 • www.spacetv.co.za...
