- Page 1 THE INTERFACER MANUAL...
- Page 2 Right in RGB LED – red = stereo, blue = mono Tuner send (directly below Right in) Right out Press in for ground lift Left out – Right out* Passive in Press in for phase Soft touch switch – inversion – Right out* †...
- Page 3 If you have a vintage fuzz or wah, or any pedal that doesn’t like being after a buffer you can use the passive input first. It’s important to return to the buffered input if you want to take advantage of the always-on tuner send. TUNER STEREO WET PEDALS (modulation, delay...
- Page 4 The Interfacer features DMS™ which stands for Dual Mode Summing. Unique circuitry, designed by Goodwood Audio, that provides two types of summing, Stereo Sum and Split Sum. The default setting is Stereo Sum.
- Page 5 L output will stay active, but the R output will have no signal. Ground Lift & Phase Correction (The TX Interfacer only) The TX Interfacer features red and black push buttons. Press the red button to lift ground of the right output. Press the black button to invert the phase of the right output by 180°...
- Page 6 Specs Power: 2.1mm barrel, centre negative, 9vDC power only! Minimum 100mA Dimensions (incl. all jacks and switches): 73mm wide x 115mm deep x 68mm high Weight: The Interfacer – 315 grams The TX Interfacer – 325 grams @goodwoodaudio info@goodwoodaudio.com...
