  • Page 1 NSQP PREMIUM HNSQP BOOSTER PUMP SYSTEM...

  • Page 3: Table Of Contents

    CONTENTS Basics Safety Instruction Features of Product Components of Product Method of Operation Installation Inspection and Maintenance Cause of Fault and Reaction Drive - Control mode - Method of pressure setting - Parameter Mode - Pr (Pump) - dr(Drive) - Fault History Table - Measures be taken in case of fault or alarm Communication(Option)
  • Page 4 Basics H NSQ 3 DRL 10-6 - 80A Manifold Size Pump Model Each of Pump Inverter Type NSQ-Drive Model Exclusive Inverter for Pump Feature Power Range : 0.75~22kW Input Power : 1Φ×200~230V (0.75~2.2kW) Specification 3Φ×380~440V (0.75~22kW) Output Power : 3Φ×380V Frequency : 50/60Hz In-Line type manifold Without H...

  • Page 5: Safety Instruction

    Safety Instructions Preface Thank you for choosing DOOCH’s high performance NSQ-Drive series. Describing specification, installation, operation, function, and maintenance of the NSQ-Drive series provided for the users who are familiar with and having basic experience in using a variable frequency drive.
  • Page 6 Safety Instructions Do not remove the cover while power is applied or the unit is in operation. Otherwise, electric shock could occur. Do not run the inverter with the front cover removed. Otherwise, you may get an electric shock due to high voltage terminals or charged capacitor exposure.
  • Page 7 Safety Instructions Cautions for Use A. Transportation and Installation Be sure to carry VFD in a proper way suitable for its weight, or it may result in damage to the VFD. Be sure to use heat-treated wooden crate when you adopt wooden packaging for the product. Do not pile up VFD's above allowable limit.

  • Page 8: Features Of Product

    Features of Product Apply advanced technology of new booster system Minimize pressure fluctuation by durable multi inverter Optomized design with controller module RS-485 comm., Ethernet and Internet remote control (OPTION) Explanation Functions PID controller PID Control by Micro Processor Sequential Operation Sequential pump run and stop Running stop and fault when low water level Dry-running protection...
  • Page 9 Product Component NSQP Booster Pump System Component Discription Quantity Comments Panel Inverter Controller Pump Manifold-Suction Standard Manifold Manifold-Discharge Standard Manifold Pressure Transmitter 4 ~ 20mA Suction Isolating Valve 1/PUMP Check Valve 1/PUMP Pressure Tank Depend on pump size...
  • Page 10 Product Component HNSQP Booster Pump System Component Description Quantity Comments Panel Inverter Controller Pump Manifold-Suction In-Line Manifold Manifold-Discharge In-Line Manifold Pressure Transmitter 4 ~ 20mA Suction Isolating Valve 1/Pump Check Valve 1/Pump Air Vent Pressure Tank Depend on pump size...
  • Page 11 Operation Method Step Operating Mode All pumps operate consistantly by a method of step operating (protects the pumps from over load) 3Pump system Pressure Stop pressure of master pump Starting Pressure Quantity q0~q1 : 1pump operate with inverter q1~q2 : 1pump operate with inverter, 1slave pump operate q2~q3 : 1pump operate with inverter, 2 slave pump operate Operate condition If the pressure of the discharge is lower than set pressure, the second pump will stat to operate.
  • Page 12 Operation Method Alternative Operation(basic) After scheduled operating or when all of the pumps stop, the master pump will alternatively change - Alternative method means all of the pumps will run sequently. - If all of the pumps stop and then reopertate, the master pump changes from pump one to pump 2 -After passing the time of the Pr-54 (lead pump alternation time : Factory setting 12hour), second pump will operate by force...

  • Page 13: Installation

    Installation Check the product specification Take the VFD out of the box, check the rating shown on a side of the product body to determine wheather the VFD specification is what you had ordered. Check also whether the product has been damaged during delivery. (refer to product components ) Installation Place Booster system is usually installed indoors, but if the system is installed outdoors, there should be covers to protect the electronic components from water, freezing and natural disaster...
  • Page 14 Drive Operation FND has five digits of 7-segment, four LED lamps to display various settings and states and consists of four buttons to operate drive or enter setting. LAMP BUTTONS Instructions on setting the pressure Warnings...
  • Page 15 Drive Operation Functional Description of each Part LED Lamps LED lamps consist of Run, Stop, Alarm1 and Alarm2 and functions of them are as follows: - Functions of each Button Turned on for waiting and flickered on operation Stop Turned on during stop Alarm1 Turned on for High Pressure/Low Pressure/Sensor Error/Low Level Alarms Alarm2...
  • Page 16 Drive Parameter Settings ex> Changing from 3,0 Bar~ 3.5 Bar Press the and check the current Pressure setting When pressing the button for one second the d 3.0 will appear and the 3.0 will keep on blinking. Press the to change the set pressure value. [Ex.
  • Page 17 Drive Pr Mode (Pump Control Mode) Change 1Φ 3Φ PARA. Factory Display Description Setting Range Setting operation Interlock PHRASE PHRASE Pr-03 1.0~25.0[bar] 16.0 Capcity Setup of Sensor 1 Pr-04 Correction Value of Sensor 1 -1.0~1.0[bar] ○ Pr-11 ○ ○ Freezing Prevention Pr-12 Starting Pressure Variation 0~2.0[bar]...
  • Page 18 Drive Pr Mode (Pump Control Mode) Pr-03 : Sensor 1 Capacity Setup Enter the maximum value that the pressure sensor can measure. By entering capacity of pressure sensor attached to the drive being used, it is possible to display the currently measured pressure. Example) In case the using sensor has 10bar, enter 10.0.
  • Page 19 Drive Pr Mode (Pump Control Mode) Pr-40 : 485 Communication Mode To set up 485. Setup Data Functional Description 0 (factory setting) Not use 485 comm. Use 485 comm. Pr-41 : 485 Communication ID set up It sets up 485 comm. ID set up Setup Data Functional Description f the number of data request protocol is different, data is not...
  • Page 20 Drive Pr Mode (Pump Control Mode) Pr-51 : Communication ID Setup It is CAN Communication ID on Multi-Drive control mode. Be sure to not duplicate ID for setup. Setup Data Functional Description 0 (Factory Setting) Single Mode Related Functions dr-02 Target Frequency Input Method Pr-52 CAN Communication Speed...
  • Page 21 Drive Pr Mode (Pump Control Mode) Pr-55 : Stand-by Pump Waiting Time on Multi-Drive Control Mode This is to give some delay to stand-by pump. If the stand-by pump starts operation before the main drive outputs maximum frequency then the pressure may increase suddenly. Pr-61 : PID Type Setup on Multi-Drive Control Mode Centralized control is a method that all of drivers participating into operation are allocated with target value for the output frequency by one PID controller of Master.
  • Page 22 Drive Pr Mode (Pump Control Mode) Pr-73 : Low Pressure Alarm Time It sets maintaining time of low pressure alarm level to issue the low pressure alarm. That is, if the current pressure decreases under the low pressure alarm level (Pr-71) and maintains its state for a specified time, a low pressure alarm is displayed and operation stops.
  • Page 23 Drive dr mode (Drive Control Mode) To setup initial value according to drive capacity To setup initial value with basis of Dooch induction motor Change 1Φ 3Φ PARA. Factory Display Description Setting Range Setting Interlock PHRASE PHRASE operation dr-01 Command Input Location Setup dr-02 Target Freq.
  • Page 24 Drive dr mode (Drive Control Mode) dr-01 : Command Input Location Setup It sets operation command location. When selecting FND key, it is possible to issue operation command using key on main body of drive. When setting up terminal block, it is possible to issue operation command using external input(P1) Setup Data Functional Description 0 (Factory Setting)
  • Page 25 Drive dr mode (Drive Control Mode) dr-22 : Rising Time It is time to reach max frequency from 0[Hz]. If rising time is too short, over- current fault may be occurred during motor operation. dr-23 : Falling Time It is time to decelerate to 0[Hz] from max frequency. If falling time is too short, over- voltage fault may be occurred during motor operation dr-37 : No.
  • Page 26 Drive dr mode (Drive Control Mode) dr-89 : Initialization Code It initializes to the factory settings. Caution : All present data will be lost once it is re-setted to the factory setting. Setup Data Functional Description 0 (Factory Setting) To maintain content To initialize dr-53, dr-54 to the factory settings dr-90 Initialization Code It initializes to the factory settings.
  • Page 27 Drive Terminal Block(Internal) Rated Input and Output (Three Phrase) Model Specification Model NSQ-_____T 0075 0150 0220 0400 0550 0750 1100 1500 1850 2200 Standard Motor [kW] 0.75 18.5 Standard Motor [HP] Output Capacity[ [kVA] 10.5 15.8 19.7 25.7 29.6 Rated Output Current [A] 380 ~ 440 Output Voltage [V] Output Frequency [Hz]...
  • Page 28 Drive Fault History Table Discription Restarting Refer to page Display Pressure Sensor Error Er-01 High Pressure Alarm Er-02 Low Pressure Alarm Er-03 Low Level Alarm Er-04 Drive Arm Short Trip Er-05 Drive H/W Over Current Trip Er-06 Drive H/W Over Current Restriction Trip Er-07 Motor Overheat (TMOH) Er-08...

  • Page 29: Cause Of Fault And Reaction

    Drive Troubleshooting Reset of fault and alarm In case of fault or alarm, FND shows Pr-80. To reset in Pr-group, Press twice. To reset in St-group, Press once. In case of Er-01, Er-02, Er-04(Low Level Sensor Alarm), If cause is resolved, it reset and restart automatically.

  • Page 30: Communication(Option)

    Troubleshooting Communication Er-04 (Low water Level Alarm-tUL)) It is an alarm generated to prevent the mechanical seal from being damaged due to running of the pump when there is no water on the suction side. It is generated when the low levelsensor (electrode) does not detect the water. In case Cause of not using the low water level sensor, the software generates the alarm when the current pressure is maintained under the low pressure alarm level (Pr-75)and operation continues for low pressure trip time(Pr-74).
  • Page 31 RS-485(Option) Communication Communication Specification Article Specification Communication Speed 1200/2400/4800/9600/19200 bps Control Procedure Asynchronous Communication Communication System Half duplex system Letter 8 bit Stop bit 1 bit Error Check (CRC16) 1 byte Parity Check None Communication Protocol(ModBus - using RTU protocol) Code Name 0 X 03...
  • Page 32 RS-485(Option) Communication Fault Diagnosis-in case the communication is not connected Check List Remark Connections between the NSQ Drive and the Check terminal block Master computer/FA equipment RS485 Pr-40 485 comm. Mode RS485 comm. speed Pr-42 485 comm. Speed RS485 comm. ID Pr-41 485 comm.
  • Page 33 Warranty This product has been manufactured through a strict quality management and inspection process by Dooch Technical Team. The warranty period is 12 months from the date manufactured, provided that, the warranty period is subject change depending on the terms and condition of the agreement under separate cover.
  • Page 34 NSQP-1507-M NSQP PREMIUM HNSQP BOOSTER PUMP SYSTEM DOOCH CO., LTD. │ 332 Hwagok-ro, Jangan-myeon, Hwaseong-si, Gyeonggi-do, Korea TEL : +82-31-831-1200 FAX : +82-31-831-1240 www.doochpump.com...
