Usage (PC)
To connect the headset to your computer (or other device) that has both a headphone jack
and a microphone jack, connect the headset's 3.5mm plug to the female jack on the audio
control box. The audio control box has two 3.5mm jacks. The audio plug, which has green
stripes, plugs into the port signified by a green input or headphone symbol . The extension
cable microphone plug, which has pink stripes, plugs into the port signified by a pink input or a
microphone symbol .
Using with PC extension cable
Usage (Xbox One)
™
To use the headset with Xbox One , connect the 3.5mm plug on the headset directly to the
3.5mm jack on the Xbox One controller
Document No. 480HX-HSCR001.A01 HyperX Cloud Revolver Headset Page 7 of 10
