TrustOne Global TSG-550

Thank you for purchasing a TSG-550.
To ensure your TSG-550 is properly set-up and installed, you must
follow our guide.
1. The TSG-550 device MUST be secured with the supplied
back plate to a hard surface (wall or desk).

2. Ensure a qualified Electrician connects the power leads to the
device.

3. Idency will be happy to support you through the install
process. Please call us on 01252 727 103 to arrange a call
with one of our engineers.

4. See our How to Install & Configure the TSG -550 video here:

hSps:/
/www.youtube.com/watch?v=W_5hQ5bv4w8

5. See our User Registra\on video here:

hSps:/ /www.youtube.com/watch?v=h9wGmNCwXAc
Company Reg No: 8965113; VAT No: GB 183 6203 13
Set-Up Guide
IMPORTANT – PLEASE READ
Idency Ltd
No.7 The Old Hop Kiln
1 Long Garden Walk, Farnham, Surrey, GU9 7HX
t: 01252 727103; e: sales@idency.com
