SUNFISH
Rigging Manual
Go-fast tip number one:
Read this rigging guide fi rst.
SUNFISH SUNFISH RACE
1
Parts of the Hull
2
Parts of the Sail
3
Sunfi sh Mast Kit
4
Bailer Installation
5
Ratchet Block Installation
6
Attaching the Sail to the Booms (Standard)
7
Attaching the Sail to the Booms (Race)
8
Rigging the Outhaul (Race)
9
Rigging the Cunningham (Race)
10
Stepping the Mast: Standard and Race
11
Attaching the Main Halyard: Standard and Race
12
Raising the sail: Standard and Race
13
Rigging the Mainsheet
14
Assembling the Rudder and Tiller
15
Attaching the Rudder: Standard and Race
16
Daggerboard Assembly: Standard and Race
17
De-rigging
18
Sail Care
Advertisement
Related Manuals for LaserPerformance SUNFISH RACE
Summary of Contents for LaserPerformance SUNFISH RACE
- Page 1 SUNFISH SUNFISH RACE SUNFISH Rigging Manual Parts of the Hull Go-fast tip number one: Parts of the Sail Read this rigging guide fi rst. Sunfi sh Mast Kit Bailer Installation Ratchet Block Installation Attaching the Sail to the Booms (Standard)
- Page 2 We suggest that you read through this guide to better familiarize yourself with the parts and rigging of your Sunfi sh. If you have any questions please contact your dealer or call LaserPerformance customer service at 1-800-966-SAIL. Mast Cap Head of sail 1.
- Page 3 Here is a list 3. Sunfi sh Mast Kit Th e Sunfi sh is available in two models; Standard and Race. Th e Race model comes with of tools needed equipment most commonly used for racing. Locate the mast, upper and lower boom. Th e upper and lower boom will be connected to assemble your at one end with two interlocking eye bolts (fi...
- Page 4 4. Bailer Installation 5. Ratchet Block Installation PLUG 1. Locate the bailer O-ring (A), cap (B), plug Depending on which model Sunfi sh you have (C) and housing (D) from the delivery kit purchased the ratchet block will be diff erent O-RING (fi...
- Page 5 6. Attaching the Sail to the Booms (Standard): 7. Attaching the Sail to the Booms (Race) 1. From the delivery kit locate the sail, upper 1. From the delivery kit locate the sail, upper and lower 6. Using one of the longer sail ties in the sail tie and lower booms, S-hook and package of sail boom, S-hook, and sail ties.
- Page 6 9. Rigging the Cunningham (Race) 11. Attaching the Main Halyard: Standard and Race 1. Using the cunningham Th e main halyard is secured to the upper boom with a clove hitch. It is suggested that you place three wraps of line, tie a bowline to the electrical tape around the upper booms between the ninth and tenth sail ring (counting from the tack of the interlocking eyebolt of the...
- Page 7 13. Rigging the Mainsheet 16. Attaching the Rudder: Standard and Race 1. Retrieve the mainsheet from the line bag. Tie a bowline to the mainsheet snap shackle with one end of the mainsheet (fi gure 49). 2. Snap the mainsheet shackle onto the bridle (fi...
-
Page 8: Owner Information
fi shclass.org. insurance information LaserPerformance equips the Sunfi sh with the highest quality parts available. We partner with key suppliers to develop top-of-the-line sailing equipment so your boat will perform at the highest level possible when sailed with the factory supplied rope, sails and hardware. Shop online at laserperformance.com or at an authorized maintenance LaserPerformance dealer to be sure you are getting genuine LaserPerformance parts and accessories. - Page 9 Laser, SB3, Sunfi sh, and Dart +971 (4) 3039 840 are trademarks used under license. +971 (4) 3039 839 LaserPerformance reserves the right to make design and/or specifi cation changes to any of their products as part of their continuous LASER PER FOR MANCE.COM...
