- Page 1 Installation instructions Ethernet switch EC2095...
-
Page 2: Table Of Contents
Ethernet switch EC2095 Contents 1 Preliminary note ..........3 1.1 Symbols used. -
Page 3: Preliminary Note
Ethernet switch EC2095 1 Preliminary note This document applies to devices of the type "Ethernet switch" (art. no.: EC2095). It is part of the unit. This document is intended for specialists. These specialists are people who are qualified by their appropriate training and their experience to see risks and to avoid possible hazards that may be caused during operation or maintenance of the de- vice. -
Page 4: Safety Instructions
Ethernet switch EC2095 2 Safety instructions 2.1 General These instructions contain texts and figures concerning the correct handling of the device and must be read before installation or use. Observe the operating instructions. Non-observance of the instructions, operati- on which is not in accordance with use as prescribed below, wrong installation or incorrect handling can seriously affect the safety of operators and machinery. -
Page 5: Features At A Glance
Ethernet switch EC2095 PDM 360 Ethernet Cameras Ethernet Switch power supply Application example 3.1 Features at a glance ● 5 ports with 10/100 Mbits/s ● Auto-negotiation Transmission speed and mode (half/full duplex) of the connected devices are recognised and set automatically. ●... -
Page 6: Installation
Ethernet switch EC2095 4 Installation 4.1 Installation position and mounting surface Installation position as required No uneven mounting surface NOTE The housing must not be exposed to any torsional forces or mechanical stress. Damage possible. ► Fix the device only on plane surfaces. ►... -
Page 7: Operating Voltage
Ethernet switch EC2095 ► Lay supply and Ethernet cables away from the device using the shortest possi- ble route. ► All connected cables must be provided with a strain relief. 5.2 Operating voltage The supply voltage can be connected to V1 or V2 as option. 2 different sources have to be connected for redundant operation, however. -
Page 8: Cover All Unused Ports
Ethernet switch EC2095 5.5.1 Cover all unused ports NOTE Moisture penetrating through unused or unprotected ports may destroy the device. ► Cover unused ports with protective caps. 6 Indicators Power LNK/ACT 1: LED Power (green) 2: LED LNK/ACT (green) Operating states (LED) → 7 Technical data 7 Set-up/Operation After installation and electrical connection the device is ready for operation. -
Page 9: Technical Data
LED for each connection Operating voltage 1 LED green (power) Ethernet 5 LEDs green (LNK/ACT) ifm electronic gmbh ● Friedrichstraße 1 ● 45128 Essen We reserve the right to make technical alterations without prior notice! EC2095 / page 1 22.02.2011... - Page 10 GND (V2) 10...30 V DC (V2) functional earth Ethernet M12 socket, D-coded, 4-poles Potential housing screen ifm electronic gmbh ● Friedrichstraße 1 ● 45128 Essen We reserve the right to make technical alterations without prior notice! EC2095 / page 2 22.02.2011...
-
Page 11: Maintenance, Repair And Disposal
Ethernet switch EC2095 9 Maintenance, repair and disposal The device is maintenance-free. ► Do not open the housing as the device does not contain any components which must be maintained by the user. The device must only be repaired by the ma- nufacturer.
