12V 12A, 24V 6A, 36V 3,6A, 48V 3A, 60V 2,5A
Pulsed charge current
-
Charger that can "listen" to the chemistry of the battery
-
Fast, smooth and battery friendly charging
-
Battery determines charging current by itself under supervision of Intelligent
-
microprocessor pulse charging system
4 charging programs, STA (standard), AGM, GEL, CaCaWET starter battery
-
There is no warming up effect, which reduces battery life at overcharge
-
4 charging phase: bulk charge, absorption, equalization, float charge
-
Regenerate cells majorly, when they were charged improperly - Battery
-
desulfatization effect
Pulse-charging prolong the battery life.
-
Safe against short-circuit
-
Precise full charge indicator (green LED)
-
Working temperature range from 0º to +35ºC
-
Charging is independent of oscillations in the supply voltage (PWM
-
technology)
START button for completely discharged battery
-
Intelligent pulse battery charger AP-180
INSTRUCTIONS FOR USE
Pulse battery charger AP–180
CHARGER CHARACTERISTICS
1
Advertisement
Table of Contents
Related Manuals for Eyra AP–180
Summary of Contents for Eyra AP–180
- Page 1 Intelligent pulse battery charger AP-180 INSTRUCTIONS FOR USE Pulse battery charger AP–180 12V 12A, 24V 6A, 36V 3,6A, 48V 3A, 60V 2,5A CHARGER CHARACTERISTICS Pulsed charge current Charger that can "listen" to the chemistry of the battery Fast, smooth and battery friendly charging Battery determines charging current by itself under supervision of Intelligent microprocessor pulse charging system 4 charging programs, STA (standard), AGM, GEL, CaCaWET starter battery...
- Page 2 Intelligent pulse battery charger AP-180 CHARGER PARTS CHARGER OVERVIEW...
- Page 3 Intelligent pulse battery charger AP-180 INSTRUCTIONS FOR CONNECTING THE CHARGER WITH BATTERY lead (Pb) Battery charger AP-180 is suitable for charging only batteries from all together capacity of min. 6Ah (at 12V charger). Maximum capacity of charged battery is not limited. Battery charger is for (we recommend that the charging time is not too long) battery systems up to 200Ah total capacity.
- Page 4 Intelligent pulse battery charger AP-180 CHARGING PROGRAMS To set the correct charging program it is necessary to remove the cover. First disconnect the charger from the network and disconnect the battery from the charger. There are 4 screws on both sides, unscrew them. Charger has 4 charging 4 types of lead batteries: standard (STA) or universal, programes for...
- Page 5 We can say that pulse charging technology works as transformer between battery chemistry and signals that commands the charge. Each battery is treated individually. Your experience with this charging method please send to info@eyra-elektronika.si . CHARGING DIAGRAM...
- Page 6 Intelligent pulse battery charger AP-180 HOW AND WHEN TO USE THE BURST CHARGING When charging an over-discharged battery which has a voltage below 6V (at 12V charger), the system does not start charging, even though the charger is properly connected. In this case, press START HELP button to activate forced charging with the single-pulse.
- Page 7 Intelligent pulse battery charger AP-180 TROUBLESHOOTING Error Cause Solution The charger is connected to the mains, - there is no mains voltage 230Vac - ensure supply voltage power switch is ON. 230Vac LED signals not blinks. Battery is connected but the charger is - to low voltage on the battery (over- - use START button not charging, all LED blinking.
- Page 8 Intelligent pulse battery charger AP-180 SERVICE AND GUARANTEE Eyra elektronika d.o.o. Gabrje pri Stični 45 SI-1295 Ivančna Gorica Slovenia Tel.++386 (0)1 7869-037 Fax++386 (0)1 7869-038 e-mail: info@eyra-elektronika.si http://www.eyra-elektronika.si GUARANTEE STATEMENT Guarantee conditions: The guarantee is valid for 24 months from the date of sale.
