- Page 1 433MHz Wire Free PIR Detector LHD100SU Instruction Guide...
- Page 2 Operating Instructions and be retained for future reference. Introduction The LuxHome PIR Detector is designed for use with LuxHome wire free Intruder Alarm Systems operating on 433MHz only. PIR Detectors are designed to detect movement in a protected area by detecting changes in infrared radiation levels caused, for example, when a person moves within or across the devices field of vision.
- Page 3 The position of the PCB inside the PIR can be set to 5 different positions to adjust the range of the PIR Detector. Setting the PCB in position 3 will reduce the range to 9m approximately, with position 1 providing a range of 6m approximately. The recommended position setting for the PCB is in position 5.
- Page 4 Note: DO NOT fix the PIR Detector to metalwork or locate the unit within 1m of metalwork (i.e. radiators, water pipes, etc) as this could affect the radio range of the device. Installing and Configuring the PIR Detectors Ensure that the system is in Test or Service Mode 1.
- Page 5 Setting the PIR Detectors Located on the PCB of the PIR Detector are two blocks of DIP switches (SW and SW3). When setting Dip Switches to House Code, hold the PIR Detector ‘upside down’ as shown in the diagram on the right: 1.
- Page 6 3. DIP 4 of SW3 is used to configure the PIR Detector for walk test mode, which allows the operation of the Detector to be checked during installation without triggering a Full Alarm. DIP 4 of SW3 Mode Trigger reaction on LED •...
- Page 7 Testing the PIR Detector Before testing the PIR Detector ensure that the system is in Test mode (for a Control Panel System) or Service Mode (for a Siren only System). With the PIR Detector set in Walk Test mode (Switch 4) and mounted in position on the wall, allow -3 minutes for the PIR Detector to stabilize before commencing the Walk Test.
- Page 8 A copy of your original invoice/receipt. b. A covering letter giving your full contact details, including email address (if applicable). c. A description of the fault or problem. LuxHome Alarm Systems Manufactured by Everspring Copyright © 013. All Rights Reserved.
