- Page 1 STEAM Simple and easy to use for cleaning hard floors & carpeted surfaces.
-
Page 3: Specifications
O2800 Steam Mop Congratulations on the purchase of your new Optim Steam Mop. There are many useful features built into your steam mop. We recommend that you carefully read this instruction manual for the best results. Features: 1. Handle 6. Power Cord 2. Cable Hook 7. Water Tank 3. Cord Storage Hook 8. Mop Head 4. Hight Adjustment Button 5. Rod Accessory: 9. Carpet Glider 10. Refill Cup 11. Mop Pads (2pcs) Specifications: Wattage: 1600W Water Tank Capacity: 250ml Cord Length: 4.8m Please contact Godfreys Customer Care 1800 815 270, to find your local... -
Page 4: Before You Begin
Before You Begin PLEASE READ THIS MANUAL BEFORE OPERATING CLEANER This will ensure you obtain full benefit from your new steam mop. Keep this Instruction Manual in a handy place for future reference. IMPORTANT Always ensure that the cleaner is in the fixed upright position and that the power plug is removed from the power supply before cleaning your appliance, when not in use, or attempting any maintenance task. This cleaner should only be used for its intended purpose as described in these instructions. PRECAUTIONARY MEASURES: 1. Do not operate the steam mop too close to heaters, radiators or other hot surfaces. 2. Before inserting the power plug into the power supply, make sure your hands are dry. 3. When unplugging the power plug from the power supply, do not use the power cable, gently pull the power plug from the power supply. BEFORE YOU CLEAN, TEST FIRST Your steam mop is designed to clean hard flooring such as ceramic tiles, vinyl, laminate, marble, stone and sealed hard wood floors. Use of your steam mop on waxed or some unwaxed floors may result in a diminished gloss. The steam mop is not for use on unsealed wood floors. For the best results test in an inconspicuous area and check the care instructions from your flooring manufacturer. - Page 5 WARNING! To reduce the risk of fire, electric shock or injury when using an electrical appliance, basic precautions should always be followed, including the following: 8. Do not pull or carry the appliance This appliance is not intended for use by persons (including children) by the power cord, do not use the with reduced physical, sensory power cord as a handle, do not or mental capabilities or lack of close a door on the power cord or experience and knowledge, unless pull the power cord around sharp they have been given supervision edges or corners. or instruction concerning use 9. Keep the power cord away from of the appliance by a person heated surfaces.
- Page 6 19. Do not fill the water tank with attachments that are not provided or anything other than water. Never sold by the manufacturer may cause put additives (such as perfume fire, electric shock or injury. disinfectant, eucalyptus oil, stain 25. Never point or aim the steam cleaner remover or products containing at people, animals or plants. alcohol) in the water tank as damage 26. Do not aim the steam cleaner at to the cleaner may result or make the electrical systems or wires. cleaner dangerous to use. 27. Connecting the steam cleaner to 20. Empty the water tank after each use. improper voltage may result in 21. Do not touch any hot areas on the damage to the steam cleaner and steam cleaner. It is normal for the possible injury. steam cleaner to heat up during 28. Do not use steam cleaner if there operation. are visible signs of damage or if it is 22. The force and heat of the steam leaking. may have an adverse effect on some 29. Do not use the cleaner on leather, wax materials. Always test the cleaner on a polished furniture or floors, synthetic small concealed area to determine if it...
- Page 7 Assembling IMPORTANT! The appliance should be disconnected from the power supply before you start to assemble. 1. Insert the handle into the main body until it locks into position. 2. Insert the main body into the mop head ensuring that it clicks into place. 3. Secure the mop head to the main body with the screw provided, as shown. 4. Attach the mop pad onto the base of the mop head.
-
Page 8: Before You Begin Cleaning
Instruction for Use Attention: DO NOT refill the tank when the mop is connected to mains power supply. Only refill the water tank with cold tap water. Before You Begin Cleaning 1. Unscrew the water tank cap and fill the water tank with cool tap water by using the refill cup provided. 2. Ensure that the cleaner is standing vertically and in the fixed position. With your foot placed onto the mop head push the handle forward to place the cleaner into the fixed position. 3. Adjust the height of the rod by pressing the Height Adjustment Button. Ensure the power cable is secured into the cable hook. -
Page 9: Steam Cleaning Hard Floors
Steam Cleaning Hard Floors NOTE: Before using the steam mop, sweep or vacuum the floor to remove any loose dirt or debris. IMPORTANT: Do not use the cleaner without a mop pad attached to the mop head. WARNING: Hard floor wax may be removed by the heat and steam action. - Page 10 Steam Cleaning Carpets NOTE: Before using the steam mop, vacuum the floor to remove any loose dirt or debris. IMPORTANT: Do not use the cleaner without a mop pad and carpet glider attached to the mop head. 1. Place the cleaner onto the carpet glider. 2. Plug the cleaner into the power supply. 3. With your foot placed onto the floor head, pull the handle backwards to unlock the cleaner.
-
Page 11: Maintenance
Maintenance WARNING! The appliance should be in the fixed position and disconnected from the power supply before performing any maintenance tasks. IMPORTANT: Always ensure that cleaner has cooled before performing any maintenance tasks. Emptying the Water Tank 1. Remove the water tank cap. 2. Empty any excess water from the water tank. - Page 12 Removing and Cleaning The Mop Pad 1. Wash the mop pad in a washing machine with a mild detergent at a max temperature of 40°C. IMPORTANT: Do not use bleach or fabric softener when washing the mop pad.
-
Page 13: Troubleshooting
Troubleshooting Problems and Solutions If you come across a problem, please use this checklist before contacting Godfreys Customer Care 1800 815 270. Fault Solutions The cleaner will E nsure that the cleaner is plugged into the power not produce supply and that the cleaner is in the unlocked steam. position. E nsure that the water tank is filled with cold water. R emove the water tank cap and reinstall the water tank cap securely. -
Page 14: Spare Parts
Spare Parts Part Part Number Steam Mop Pads 2pk 31400144... - Page 16 STEAM Conditions of warranty Your OPTIM Steam Mop, in the case of Waverley Victoria 3150, or on 1300 360 845, domestic use, has a 3 month parts and labour Monday-Friday 9am-5pm EST. The decision warranty against product defects and failures to repair or replace the cleaner is at the when the product is used in accordance with sole discretion of Godfreys Customer Care. the terms and conditions of this warranty If Godfreys Customer Care decide to repair statement.
Need help?
Do you have a question about the O2800 and is the answer not in the manual?
Questions and answers
How fill water
To fill water in the Optim O2800:
1. Ensure the mop is unplugged from the mains power supply.
2. Unscrew the water tank cap.
3. Use the provided refill cup to fill the tank with cool tap water.
4. Securely reinstall the water tank cap.
This answer is automatically generated
