RIVVAL RP05520/10 Manual

Gator pneumatic magnetic drilling machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GATOR PNEUMATIC MAGNETIC
DRILLING MACHINE
Model No. RP05520/10
RIVVAL LTD,
Registered Office: RIVVAL Ltd.,
Oakdale,
Carrickasedge,
Carrickmacross,
Co. Monaghan,
Ireland.
Tel: +353 42 969 0882
Web: www.rivval.com
Email:
sales@rivval.com
Company Number: 390186
VAT Number: 6410186G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP05520/10 and is the answer not in the manual?

Questions and answers

Related Manuals for RIVVAL RP05520/10

Summary of Contents for RIVVAL RP05520/10

  • Page 1 GATOR PNEUMATIC MAGNETIC DRILLING MACHINE Model No. RP05520/10  RIVVAL LTD, Registered Office: RIVVAL Ltd., Oakdale, Carrickasedge, Carrickmacross, Co. Monaghan, Ireland. Tel: +353 42 969 0882 Web: www.rivval.com Email: sales@rivval.com Company Number: 390186 VAT Number: 6410186G ...

  • Page 3: Contents Of The Manual

    Issue 4 Original version March 2010 CONTENTS OF THE MANUAL Specification of machine General procedure and safety measures Operating instructions Mounting of cutters Remedies for hole making problems Component parts of complete machine Exploded view Optional Extras Maintenance [10] Pipe adaptor Kit [11] Warranty List of contents with drill unit...

  • Page 4: Specification

    Issue 4 Original version March 2010 [1] SPECIFICATION Maximum hole cutting capacity in .2/.3C steel 52mm dia., 52mm deep. Arbor bore 19.05mm dia. (3/4" dia.) Motor Unit: *Speed 630 rpm *Torque 4.0 da Nm (cont) *kW 2.4 (cont) Magnet: Manually operated Tractive force at 20°C(25mm min.

  • Page 5: Safety Procedures

    Issue 4 Original version March 2010 [2] SAFETY PROCEDURES READ BEFORE USING THE MACHINE Always secure the machine with the safety strap RD4329 before starting to operate - for the user's protection in case the magnetic base breaks loose whilst in use. Failure to do so may result in personal injury. Always wear approved eye and ear protection when the equipment is in operation.
  • Page 6 Issue 4 Original version March 2010 [3] OPERATING INSTRUCTIONS Before connecting the hydraulic supply ensure the motor switch is in the OFF position. Locate the machine in the required position for cutting the hole and activate the magnet by means of the ratchet handle (clockwise viewed from rear).

  • Page 7: Mounting Of Cutters

    Issue 4 Original version March 2010 [4] MOUNTING OF CUTTERS The following procedure is to be used when mounting cutters. ALWAYS DISCONNECT MACHINE FROM HYDRAULIC SUPPLY Lay the machine on its side with feed handles uppermost, ensuring arbor is wound down to its lowest point to enable access to socket screws RD4066.
  • Page 8 Issue 4 Original version March 2010 Excessive cutter breakage Steel swarf or dirt under cutter Remove cutter, clean part thoroughly and replace Incorrectly re-sharpened or worn cutter Always have a new cutter on hand to refer to for correct tooth geometry, along with instruction sheet Cutter skipping See cause and remedy above...
  • Page 9 Issue 4 Original version March 2010 [6] PARTS LIST - RD140 Item Component Part No Item Component Part No Rack RD3350 Guard Bracket RD33000 Fixed Gib Strip RD3317 Spring Plunger RD4346 Adjustable Gib Strip RD3316 Button RA354 Gib Support Strip RD3310 Spring RA355...
  • Page 10 Issue 4 Original version March 2010 [7] EXPLODED VIEW – RD140...

  • Page 11: Optional Extras

    [8] OPTIONAL EXTRAS ROTABROACH CUTTING FLUID ROTABROACH CUTTING FLUID has been formulated to give maximum life to your ROTABROACH CUTTERS RD208 Available in three sizes: RD208 1 litre RD229 5 litres RD220 25 litres CHUCK RD4189 1/2” capacity chuck + key RD4190 Chuck key RD324 Chuck spacer This chuck can only be fitted to drill units having a...
  • Page 12 Issue 4 Original version March 2010 [9] Tips for keeping your machine in correct working order. In order to ‘get the best life’ out of your Rotabroach machine always keep in good working order. A well maintained machine is a happy machine. A number of items must always be checked on Rotabroach machines.
  • Page 13 Issue 4 Original version March 2010 Adjustment of slide and bearing bracket Alignment. An essential requirement of the machine is that the slide can move in a smooth and controlled manner, free of lateral movement and vibration. This situation can be maintained by periodic adjustment of the slide and is accomplished in the following manner: 1.

  • Page 14: Pipe Adaptor Kit Rd2311

    Issue 4 Original version March 2010 [10] PIPE ADAPTOR KIT RD2311 FITTING INSTRUCTIONS  Dependent upon the size of the pipe to be cut (see illustrations) attach adjustable angle plates RD3328 with cap screws RD4325 and washers RD4205 (4 off each) to the magnet sides. Do not tighten.
  • Page 15 Issue 4 Original version March 2010 NOTES:...

  • Page 16: Warranty Statement

    Issue 4 Original version March 2010 WARRANTY STATEMENT Rotabroach® warrants its machines to be free from faulty materials, or workmanship under normal use for a period of 6 months from initial date of purchase and 90 days for all other parts (excluding cutters), provided that the warranty registration card (or online registration) has been completed and returned to Rotabroach®, or its designated distributor within a period of (30) days from the purchase date, failure to do so will void the warranty.
