- Page 1 Calibur Kalatel KA2 ProBridge Product Overview & Installation Manual Calibur Kalatel KA2 ProBridge 0150-0217B...
- Page 2 Warning! To prevent fire and electronic shock, do not expose this product to rain or moisture. The lightning flash with the arrowhead The exclamation point, within an equilateral symbol, within an equilateral triangle, is triangle, is intended to alert the user to the intended to alert the user to the presence of presence of important operating and uninsulated “dangerous voltage”...
-
Page 3: Table Of Contents
KA2 ProBridge ............... 4 Kalatel KA2 ProBridge Description............. 4 Compatibility ..................4 Installation Environment ..............4 Power ....................5 Installation Steps Summary ............... 6 Connection Diagrams................ 7 Cable Specifications............8 Troubleshooting............. 9 Unit Settings ..............10 Configuring ProBridge Jumpers............10 Specifications .............. -
Page 4: Ka2 Probridge
1 KA2 ProBridge 1.1 Kalatel KA2 ProBridge Description The Kalatel CBR-PB2-KA2 is a specific ProBridge unit for interfacing the DVMRe family of digital video multiplex/recorders to Kalatel PTZ Cyberdomes where local keyboard control is not already provided via a CBR-KB3 or KTD-405 keypad. The CBR-PB2-KA2 combines into a single unit the services of both a CBR-PB2- KAL and a KTD-410 previously required for all Cyberdome installations. -
Page 5: Power
1.4 Power The ProBridge is furnished with a power supply (110 or 240 VAC). Do not use any other power supply with this product. The manufacturer accepts no responsibility for damage caused by the use of any other power supply. Make sure installation is complete and all connections are made before applying power to the unit. -
Page 6: Installation Steps Summary
1.5 Installation Steps Summary Carefully and completely read the manuals for each piece of equipment before attempting to install and connect this equipment. Before you start connecting telemetry and other optional accessory equipment to your system, make sure that all, power, video, VCR, and monitor connections are completed, and everything is working correctly. -
Page 7: Connection Diagrams
1.6 Connection Diagrams This drawing depicts one Cyberdome connected via an RS485/422 network to a Calibur Triplex unit that provides remote PTZ control over Ethernet via WaveReader software. Kalatel CyberDome Kalatel Interface Connector Card 4310-0032A Cable MUX/DVMR RCVR/DVR Kalatel KA2 ProBridge 4310-0034B Cable DVMRe Triplex... -
Page 8: Cable Specifications
2 Cable Specifications ProBridge to Calibur Unit Cable (RS-485) Part Number : 4310-0034B Pin 8: Brown Do Not Connect Pin 8: Brown Communication Type: RS-485 Pin 7: Brown/White Pin 7: Brown/White Pin 6: Green Pin 6: Green Connector Type: RJ-45 ,RJ-45 Pin 5: Blue/White Pin 5: Blue/White Pin 4: Blue... -
Page 9: Troubleshooting
3 Troubleshooting If you are unable to verify control of the PTZ camera, please do the following: Check that each device is properly powered. Check that all cables and cable connections are correct If the interface still does not work correctly contact Tech Support. Calibur Kalatel KA2 ProBridge 0150-0217B... -
Page 10: Unit Settings
4 Unit Settings 4.1 Configuring ProBridge Jumpers The unit ships from the factory with the correct settings for most applications and should not require the installer to open the unit and change the jumper settings. However, for trouble shooting purposes we have included the default jumper settings. - Page 11 Default Jumper Settings The default jumper settings are listed below: PIN # DEFAULT STATUS RS485 Position RS485 Position RS485 Position RS485 Position P6 Pin 1 Installed P6 Pin 2 Installed P6 Pin 3 Not Installed P6 Pin 4 Not Installed P6 Pin 5 Not Installed P6 Pin 6...
-
Page 12: Specifications
5 Specifications Physical Housing Plastic enclosure. Dimensions 1.5 x 4.4 x 3.3 in. (38 x 112 (W x L x H) x 84 mm) Nominal Weight 4.8 oz (136 g) Shipping Weight 1 lb (453 g) packaged, including the external AC power supply and manual. -
Page 13: Appendix
6 Appendix 6.1 RS-485 Addressing and Connections The Kalatel ProBridge (CBR-PB2) is not an addressable device NOTE and requires no user settings. The device simply acts as an interpreter, translating the remote telemetry commands into a format useable by the P/T/Z controller. Each camera input, whether a fixed camera or a Pan/Tilt/Zoom (P/T/Z) unit, is connected to a Calibur unit input. - Page 14 Calibur Unit Receiver Address Camera Range Address Range 1-32 00-31 33-64 32-63 65-96 64-95 97-128 96-127 129-160 128-159 161-192 160-191 193-224 192-223 225-256 224-255 481-512 480-511 When more than eight Calibur units are installed, use the following formula: Telemetry Receiver Address = 32 x (Multiplexer ID - 1) + Camera Number - 1 In other words, telemetry receiver units connected to the inputs of the first Calibur have addresses of 0 to 31.
- Page 15 CALIBUR UNIT RS485 ADDRESSES CyberDome Addressing Camera Inputs 17-32 are not available on DVMRe and DVMRe NOTE Triplex units. Dome addresses, for those inputs are not useable. Calibur Kalatel KA2 ProBridge 0150-0217B...
-
Page 16: Using Calibur Keypads
Using Calibur Keypads Keyboards (CBR-KB3/J and KTD-405) are typically used to provide initial configuration of the Kalatel PTZ unit for setting PTZ addresses and presets. Please refer to the installation manual for the respective keyboard for setup and use with Kalatel PTZ units. In some specific cases keyboards may be used in conjunction with NOTE the CBR-PB2-KA2 units where multiple Calibur units are being... -
Page 17: Warranty And Service
7 Warranty and Service 7.1 Factory Service If the unit requires factory service, contact the dealer who supplied the unit to you for the correct procedures on returning the unit to the factory or the nearest factory service center. If the dealer is not available, contact the manufacturer of the unit as detailed below and request a Return Material Authorization number (RMA). - Page 18 Note: Customers requesting an estimate prior to repair will be notified by phone. If they cannot be reached, they will be notified by fax. If we are unable to reach the contact person for repair authorization after one phone attempt and two fax attempts, the equipment will be returned without being repaired.
