LNC
input
Mains socket
Audio output
digital (electrical)
LED display
Card reader for CONAX Smartcard:
> Insert the CONAX Smartcard (gold-coloured chip at the bottom,
and in the direction of insertion) carefully into the card reader as
far as it will go.
SCART socket
Audio output
digital (optical)
Audio outputs
analogue
Inserting the CA module:
> Please follow the instructions of the manufacturer of the CA
module and card.
> Insert the desired Smartcard in the appropriate CA module.
> Now insert the CA module carefully in the slot provided.
RS 232
interface
4
Programme select
up/down
SCART socket
VCR TV
On/Stand-by
