- Page 1 Connect-EV Electric Vehicle Charger Isolation Unit Installation Manual V1.0 Feb 2019...
-
Page 2: Table Of Contents
This product must be installed by a competent person in accordance with the IEE Wiring Regulations, BS7671 (18 Edition or later) and current Building Regulations. Ensure the electrical supply is disconnected before installation or removing the covers of the Connect-EV. P a g e... -
Page 3: Product Description
Connect- Product Description Connect-EV is designed for use in domestic and light commercial / retail matt:e applications where an Electric Vehicle charger is installed. The unit is not intended for any purpose other than that defined within this document. WARNINGS Please read and observe the following notices carefully. -
Page 4: Introduction
Connect- Introduction matt:e Connect-EV is a single phase solation solution designed to facilitate the installation of an electric vehicle charging systems. Rated at 32A, the unit is suitable for single phase EV charger systems up to 7kW. It is essential to check the rating of the EV charger system is compatible with the unit before installing. -
Page 5: Dimensions & Mounting The Unit
Connect- Please refer to the following diagrams for the dimensions and mounting arrangements of the unit. P a g e... - Page 6 Connect- P a g e...
-
Page 7: Electrical Connections
Connect- Electrical Connections The user wiring connections are indicated in the diagram below. Connect the incoming (live) cable from the consumer unit to the isolator. Connect the outgoing cable to the RCDA. Use of SWA cable may compromise the earthing arrangement. Please check before using SWA cable On completion of installation the tightness of all electrical connections should be checked before energising the unit. - Page 8 Connect- P a g e...
-
Page 9: Specifications
V1.0 Feb 2019 Revision Warranty The Connect-EV is guaranteed for a period of 12 months from the date of manufacture. This warranty is limited to the replacement of faulty components only. matt:e Ltd, Unit 5 Common Barn Farm, Tamworth Road, Lichfield WS14 9PX...
