Summary of Contents for Harvest Pro Terp Trap Bath 801521
- Page 1 Terp Trap Bath #801521 Harvest Pro Terp Trap Bath -40 degree #801522 Harvest Pro Terp Trap Bath -80 degree...
- Page 2 THANK YOU THANK YOU for purchasing a Harvest Pro product. We know that customers have many choices when purchasing laboratory equipment. We appreciate you choosing Harvest Pro. BEFORE YOU USE THE UNIT, read this entire manual carefully to understand how to install, operate and maintain the unit in a safe manner.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents ................ 3 Warning Symbols ............... 4 Environmental Conditions ............4 Key Features ................5 The Exterior ................6 Main Components ..............7 Installation .................. 8 Settings and Operation ............1 1 Specifications ................14 Maintenance and Service ............ -
Page 4: Warning Symbols
WARNING SYMBOLS Be sure you that you understand all of these symbols before operating the unit. Read this manual carefully. This symbol means that you should not do it. Be careful about voltage! Hot surface or steam. ENVIRONMENTAL CONDITIONS • Indoor use. -
Page 5: Key Features
KEY FEATURES Circuit breaker switch • • Over-current protection Rust-free stainless coil function TC3YF ℉ ℃ COMP ↕ • • Glass trap easily opens Digital display of temp and time • • Support multi glass trap Multi key-in [ 100Ω ( DIN Pt100Ω ) •... -
Page 6: The Exterior
THE EXTERIOR #801521 Harvest Pro Terp Trap Bath -40 degree #801522 Harvest Pro Terp Trap Bath -80 degree... -
Page 7: Main Components
MAIN COMPONENTS... -
Page 8: Installation
INSTALLATION Please carry the equipment safely. Multiple people needed to move unit. Terp Trap should be mounted on non-flammable surface material. B Once the unit is C Unscrew the bottom of D Lift the crate as shown delivered, place the the crate. - Page 9 Figure A H Make sure to unlock casters I Make sure you plug into appropriate voltage while moving Terp Trap. source. See faceplate (Figure A) for required voltage power. Load Figure B Ground J Locate Terp Trap between vacuum oven and pump. K Make sure your Refer to flask connecting illustration (Figure B).
- Page 10 Oven and Pump connection 1. Install the vacuum valve in your preferred configuration (see diagrams below). 2. Before operating, ensure that the vent valve and vacuum valve are closed. 3. Connect the tri-clamps and tri-clamp O-rings to the oven and to the vacuum pump. 4.
-
Page 11: Settings And Operation
SETTINGS AND OPERATION Use a dry cloth to clean the Terp Trap as needed. Alcohol Use of solvents and some detergents can oxidize the Terp Trap causing undesired deposits. B Start the unit Turn on main power switch (circuit breaker switch) to power up controller display(s). Push on/off switch to start the equipment. - Page 12 D Temp checking and setting...
- Page 13 E Changing Unit Temp Do not make any setting changes in engineering mode display area (see highlighted area to left).
-
Page 14: Specifications
SPECIFICATIONS #801521 Harvest Pro Terp Trap Bath #801522 Harvest Pro Terp Trap Bath -40 degree -80 degree FRONT BACK FRONT BACK SIDE SIDE MODEL #801521 -40 degree MODEL #801522 -80 degree Temp Controller Microprocessor digital controller Temp Controller Microprocessor digital controller Temp Control Range -40°F to -4°F (-40°C to -20°C) -
Page 15: Maintenance And Service
MAINTENANCE AND SERVICE • Operate this unit for 30 minutes before using with product (no load) to help the equipment run safely and remove of any moisture inside chamber. • It is recommended to perform “drying-out” (no load operation for 30 minutes) at least once a month while the equipment is not used. - Page 16 Harvest Pro 3204 NW 38th Circle Vancouver, WA 98660 360.883.8846 © 2018 Hawthorne Gardening Co. 071218BV...
