STUDIO DUE CityColor400 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Safety informations .......................................................................................................................... page 1
Technical features ............................................................................................................................. page 2
Photometric parameters .................................................................................................................. page 2
Before using ...................................................................................................................................... page 3
Main supply connection, DMX signal connection / fuses replacement ....................................... page 4
Lamp installation, replacement ....................................................................................................... page 5
Control panel and configuration ..................................................................................................... page 6
Use of the CityColor 400 .................................................................................................................. page 6
DMX line and terminator .................................................................................................................. page 8
Automode functioning ..................................................................................................................... page 8
DMX channels assignment .............................................................................................................. page 9
Games table ...................................................................................................................................... page 10
Technical drawings, spare parts, electric diagrams ........................................................................ page 11
4 0 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CityColor400 and is the answer not in the manual?

Questions and answers

Related Manuals for STUDIO DUE CityColor400

Summary of Contents for STUDIO DUE CityColor400

  • Page 1: Table Of Contents

    Safety informations .......................... page 1 Technical features ..........................page 2 Photometric parameters ........................page 2 Before using ............................page 3 Main supply connection, DMX signal connection / fuses replacement ........page 4 Lamp installation, replacement ....................... page 5 Control panel and configuration ..................... page 6 Use of the CityColor 400 ........................

  • Page 2: Safety Informations

    The CityColor400 comes in unique version: • Art. 0302 CITYCOLOR400 for two CDM-T 150W discharge lamps The fixture can work in automatic mode or in synchro mode, otherwise may be controlled by 8 bit DMX controllers The input protocol is the DMX 512. To drive the fixture we suggest to use either our Control Show 512, Fancy or the Easy Control.

  • Page 3: Technical Features

    YOUR REFERENCE Always remember to give the serial number and to specify the model any time you address the seller for information or assistan- BASIC KIT The basic kit of the CityColor400 flood projector consist of: •Projector •User’s manual •Studio Due warranty •Lamps (upon request)

  • Page 4: Before Using

    In case of installation of the spot to a truss, check carefully that the fixture is fixed with a chain to both truss and unit. g) Do not handle the spot by taking it by the head, but always by using the handles. ® CITYCOLOR400 art. 0302 CITYCOLOR400 art. 0302 Do not open for 300 seconds after the switching off.

  • Page 5: Main Supply Connection, Dmx Signal Connection / Fuses Replacement

    MAIN POWER AND DMX CONNECTION 1) Disconnect power before lamp’s replacement or servicing (service personnel) 1) Open the rear box cover. • The fixture can be equipped for 200/208/230/240Vac, 50Hz main voltage (pict.1a/1b). On request 60Hz. 3) Insert the main power cable into the PG (pic.3), connect the cable to the main power connector (pic2) and tighten the PG. 3) If necessary (synchro-mode), insert the the DMX cables into the PG (pic.3), connect the cables to the DMX connector (pic2) and tighten the PG.

  • Page 6: Lamp Installation, Replacement

    LAMP'S INSTALLATION OR REPLACEMENT 1) Disconnect power before lamp’s replacement. Wear gloves and goggles. 2) Tighten the two pommels (P) and lock the fixture's head as shown in pict.4 3) Unscrews the 4 screws (A) and remove the head cover, pict.4 4) Remove the nuts (S) to the dichroic group and open it with care, pict.5 5) Unscrews the screws (S1) and remove the two lateral reflectors (C1), pict.6 6) Insert the lamp into the lampholder (D) and repeat this procedure for the other lamp, pict.7...

  • Page 7: Control Panel And Configuration

    CONTROL PANEL On the control panel of the CityColor (pict.8) you can find, besides the display, the leds and the buttons to use to set the spot. • “DMX” led flashing: DMX input present off: no DMX input • ”LAMP” led flashing: the lamp switching off is remotely controlled off:...
  • Page 8 LHrS (Lamp Hours) To visualise the number of working hours of lamp press ENTER. The maximum countable number of hours is 3000. Exceeding this number, the display will show gr3t (greater than 3 thousands). To reset the counter press simultaneously buttons Down and UP: the display will show CLLH (clear lamp hours). To go back to the options without making any change, press the MENU button.

  • Page 9: Dmx Line And Terminator

    DMX TERMINAL LINE WARNING The wrong connection of the terminal line or its non-connection are probably the most frequent reasons for the defective functioning of the DMX line. The terminator is a resistor fitted between the two “data” lines (shown in pict.11) at the end of the cable furthest from the transmitter.

  • Page 10: Dmx Channels Assignment

    EXAMPLE OF CONNECTION AND SETTING OF 4 FIXTURE IN SYNCHRO - MODE MASTER SLAVE SLAVE SLAVE WARNING The cables are the same as the DMX standard cable DMX CHANNEL ASSIGNMENT Here below you can find the complete list of DMX values (ref. page 7) ...

  • Page 11: Games Table

    GAMES TABLE Here below you can find the complete list of the available games (ref. page 8) PROGRAM FUNCTIONS Red Magenta Yellow –color mix sequence (slow – 30sec) Red Magenta Yellow + White color mix sequence (slow – 30sec) Green Cyan Yellow – color mix sequence (slow – 30sec) Green Cyan Yellow + White color mix sequence (slow –...

  • Page 12: Technical Drawings, Spare Parts, Electric Diagrams

    4 0 0 SPARE PARTS, TECHNICAL DRAWINGS and SCHEMATIC DIAGRAMS PARTI DI RICAMBIO, DISEGNI TECNICI e SCHEMI ELETTRICI Description 480 mm Sleel grid Aluminium cover Adhesive Tempered satin glass Reflector (upper / lower) Lateral unshaped reflector Main reflector Main reflector support (fan side) Main reflector support Upper Z plate Lower Z plate...
  • Page 13 •A/BASE• ... 12 ...
  • Page 14 •B/HEAD• ... 13 ...
  • Page 15 MAIN BOARD CONNECTION LED +5V OPTO DMX U5 U6 U7 U8 U9 L6219 MOTOR DRIVER U13 78M05 OPTO DMX U4 MICRO SLAVE MOTOR U3 MICRO MASTER MOTOR CCSLAVEXX U11 VIPER SWITCHING LED +5V CC3DRVXX POWER SUPPLY DRIVER TO DISPLAY PCB PAN IP 320V DC LED DMX SIGNAL...
  • Page 16 MOTORS BOARD • POWER SUPPLY +30V Led On • +5V Led • +320V Led •+5V DMX Led • DMX signal Led flashing: the DMX signal is operating on the board Led off: check the U1 (6N137) and the DMX connecting cable (from PCB PAN IP) •...
  • Page 17 •panip400• •panipS400• ...16 ...
  • Page 18 •ccip400• ...17 ...
  • Page 19 •ccipS400• ...18 ...
  • Page 20 NOTE ...19 ...
