MP
Overview
MSR Slot
ON/OFF Button
Paper Feed
AC Adapter
Button
IrDA Window
Mobile Printer
300
Quick Start Guide
Platen
Roller
Paper Door
Pull Lever
Paper
Compartment
Port
Serial Port
1
Install Battery
1. Unlock the battery door by sliding
the battery door tab down.
2. Open the battery door to a 90 degree angle
(Do Not Force Open).
3. Insert the battery as shown
(Non-contact end first -
let the contact end drop into place).
4. Close the battery door
by sliding the battery door tab up.
Note: Ensure that the battery side with two contact terminals are
facing down, making contact with the spring probes inside the battery
compartment.
2
Charge Battery
1. Plug the AC adapter output cable into
the AC adapter port.
Metal
Tear Bar
2. Plug
the AC adapter output cable into
the appropriate AC line voltage socket.
3. The LED will illuminate indicating that the
battery is being charged.
4. After 180 minutes of fast charging the
LED will turn off.
Battery Door Tab
Li-Ion Battery
Advertisement
Table of Contents
Related Manuals for Unitech MP300
Summary of Contents for Unitech MP300
-
Page 1: Install Battery
Install Battery 1. Unlock the battery door by sliding the battery door tab down. 2. Open the battery door to a 90 degree angle (Do Not Force Open). Battery Door Tab 3. Insert the battery as shown (Non-contact end first - let the contact end drop into place). -
Page 2: Power On The Printer
Install Paper Power On the Printer 1. Open the paper supply cover by placing your fingures 1. Press the on/off button to turn the printer on. under the “T” paper door pull lever, and pull up firmly on the supply cover until the lever stops moving. 2.
