Black & Decker 90541667 Instruction Manual

19 inch (483mm) cordless mulching rear bag mower

Advertisement

Available languages

Available languages

19 Inch (483mm) Cordless Mulching Rear Bag Mower
Go to www.BlackandDecker.com/NewOwner to register your new product.
P P L L E E A A S S E E R R E E A A D D B B E E F F O O R R E E R R E E T T U U R R N N I I N N G G T T H H I I S S P P R R O O D D U U C C T T F F O O R R A A N N Y Y R R E E A A S S O O N N : :
If you have a question or experience a problem with your Black & Decker purchase, go to
If you can't find the answer or do not have access to the internet, call 1-800-544-6986 from 8 a.m. to 5 p.m. EST Mon. -- Fri. to speak with an agent.
KEY INFORMATION YOU SHOULD KNOW:
• Do not operate mower unless handle is locked into position.
• For best cutting results, keep blade sharpened and balanced.
• Inspect and thoroughly clean your mower after each use (a deck with caked grass will degrade performance).
• Make sure mowing area is clear of other persons or pets prior to starting and during operation.

INSTRUCTION MANUAL

Thank you for choosing Black & Decker!
for instant answers 24 hours a day.
Please have the catalog number available when you call.
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
VEA EL ESPAÑOL EN LA CONTRAPORTADA.
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA.
ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
Catalog Number
CMM1200
Date Code:
HTTP://WWW.BLACKANDDECKER.COM/INSTANTANSWERS

Advertisement

Table of Contents
loading

Summary of Contents for Black & Decker 90541667

  • Page 1: Instruction Manual

    19 Inch (483mm) Cordless Mulching Rear Bag Mower INSTRUCTION MANUAL Thank you for choosing Black & Decker! Go to www.BlackandDecker.com/NewOwner to register your new product. P P L L E E A A S S E E R R E E A A D D B B E E F F O O R R E E R R E E T T U U R R N N I I N N G G T T H H I I S S P P R R O O D D U U C C T T F F O O R R A A N N Y Y R R E E A A S S O O N N : : If you have a question or experience a problem with your Black &...
  • Page 2: Safety Guidelines - Definitions

    SAFETY GUIDELINES - DEFINITIONS It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 3 3. Never tamper with safety devices. Check their proper operation regularly. 4. Keep mower free of grass, leaves, or other debris build-up. Allow mower to cool before storing. 5. If you strike a foreign object, release bail handle to turn mower off, wait for the blade to stop and remove the safety key and then inspect the mower.
  • Page 4: Charging Procedure

    PREPARATION PLEASE REFER TO DIAGRAMS (A, B, C...) AND ITEM NUMBERS (1, 2, 3...) AS NOTED THROUGHOUT MANUAL. FOR EXAMPLE, A-1 REFERS TO ITEM 1 IN FIGURE A. UNPACKING Your mower has been completely assembled at the factory except for the grass bag.
  • Page 5: Removing Mulch Insert

    OPERATION PLEASE REFER TO DIAGRAMS (A, B, C...) AND ITEM NUMBERS (1, 2, 3...) AS NOTED THROUGHOUT MANUAL. FOR EXAMPLE, A-1 REFERS TO ITEM 1 IN FIGURE A. KNOW YOUR MOWER READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR MOWER. See diagram G to familiarize yourself with the location of various controls and adjustments referenced below.
  • Page 6: Maintenance

    THE FOLLOWING SUGGESTIONS WILL HELP YOU TO OBTAIN OPTIMUM RUN TIME FROM YOUR CORDLESS MOWER: 1. Slow down in areas where the grass is especially long or thick. 2. When mulching, avoid cutting more than 1-1/2 inches off the length at any one time.
  • Page 7: Off-Season Storage

    PREVENTING CORROSION Fertilizers and other garden chemicals contain agents which greatly accelerate the corrosion of metals. If you mow in areas where fertilizers or chemicals have been used, the mower should be cleaned immediately afterward as follows: (1) Release bail handle to turn mower off and remove safety key.
  • Page 8: Service Information

    Three good ideas to enhance your lawn’s appearance: Vary the mowing direction frequently; mow horizontally on hillsides; (this is also a good safety practice) and do not forget to overlap the mowing path on each pass. 10. Always mow grass so that clippings are discharged onto cut lawn. This will keep your lawn looking fresh by avoiding “Cut Grass”...
  • Page 9: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE PROBLEM Mower doesn’t run when bale handle is activated. Motor stops while mowing. Mower runs but cutting performance is unsatisfactory, or does not cut entire lawn. Mower is too hard to push. Mower is abnormally noisy and vibrates. NOTE Should the red light remain on after charging the battery for 24 hours on initial charge, the mower can still be used.
  • Page 10 GRASSBAG SAC À HERBE BOLSA PARA PASTO FRAME CADRE BASTIDOR CLIP PINCE PINZA...
  • Page 11 Cône bords Bordes biselados...
  • Page 14 Tondeuse-déchiqueteuse sans fil de 483 mm (19 po) avec bac arrière GUIDE D’UTILISATION Merci d’avoir choisi Black & Decker! Consulter le site Web www.BlackandDecker.com/NewOwner pour enregistrer votre nouveau produit. À L L I I R R E E A A V V A A N N T T D D E E R R E E T T O O U U R R N N E E R R C C E E P P R R O O D D U U I I T T P P O O U U R R Si des questions ou des problèmes surgissent après l’achat d’un produit Black &...
  • Page 15 LIGNES DIRECTRICES EN MATIÈRE DE SÉCURITÉ - DÉFINITIONS Il est important de lire et de comprendre ce mode d’emploi. Les informations qu’il contient concernent VOTRE SÉCURITÉ et visent à ÉVITER TOUT PROBLÈME. Les symboles ci-dessous servent à aider à reconnaître cette information. DANGER : indique une situation dangereuse imminente qui, si elle n’est pas évitée, entraînera la mort ou des blessures graves.
  • Page 16 18. L’utilisation de tout accessoire ou pièce non recommandés avec cette tondeuse s’avérer dangereuse. N’utiliser que les accessoires approuvés par Black & Decker. 19. Ne jamais trop tendre les bras en utilisant la tondeuse. Toujours s’assurer de conserver son équilibre à tout moment au cours de l’utilisation de la tondeuse.
  • Page 17 • NE JAMAIS mettre d’écouteur de radio ou de musique pendant l’utilisation de la tondeuse. • ATTACHER les cheveux longs. • NE JAMAIS essayer d’ajuster la hauteur des roues avec le moteur en marche ou lorsque la clé de sûreté est engagée dans le contact. •...
  • Page 18 chaleur (comme les radiateurs, appareils de chauffage, cuisinières, etc.), des flammes ou de produits chimiques. Tenir le cordon du chargeur à l’écart de bords tranchants pour ne pas l’endommager. AVERTISSEMENT : RISQUE D’INCENDIE DÉBRANCHER SYSTÉMATIQUEMENT LE CHARGEUR DE LA SOURCE D’ALIMENTATION (PRISE MURALE) AVANT DE RETIRER LE CONNECTEUR DU CHARGEUR.
  • Page 19: Entretien

    INSTALLATION DE L’INSERT DE DÉCHIQUETAGE 1. Refaire les étapes 1 et 2 pour retirer l’insert de déchiquetage. 2. Faire coulisser l’insert de déchiquetage I-3 dans l’ouverture de la décharge jusqu’à ce qu’il repose bien contre le châssis. 3. Relâcher le panneau arrière et s’assurer qu’il est correctement fermé.
  • Page 20: Quilibrage De La Lame

    4. Enlever la cale métallique carrée de la lame O-2, l’isolant plastique carré de la lame O-3 et la lame O-4 comme indiqué à l’illustration O. Examiner les défauts de l’isolant de la lame et le remplacer si nécessaire. 5. Lors du remplacement d’une lame aiguisée ou neuve sur l’épaulement du ventilateur O-5, s’assurer que le «...
  • Page 21 AVERTISSEMENT : l’utilisation de tout accessoire non recommandé avec cet outil pourrait s’avérer dangereuse. p/n 242354-01 PROTECTEUR DE L’ÉJECTEUR p/n 242867-00 GOULOTTE À ÉJECTION LATÉRALE p/n 242501-05 COLLECTEUR D’HERBE DE RECHANGE MB-1200 LAME DE RECHANGE VOICI QUELQUES CONSEILS PRATIQUES POUR OPTIMISER L’UTILISATION DE VOTRE TONDEUSE SANS FIL BLACK &...
  • Page 22: Guide De Dépannage

    PROBLÈME La tondeuse refuse de démarrer lorsque la manette-étrier est actionnée. Le moteur s’arrête en cours de coupe. La tondeuse fonctionne mais le rendement est insatisfaisant ou la tondeuse ne coupe pas toute la pelouse. Il est trop difficile de pousser la tondeuse. La tondeuse produit des sons anormaux et vibre.
  • Page 23 Podadora desbrozadora inalámbrica de 483 mm (19 pulg.) con bolsa colectora trasera MANUAL DE INSTRUCCIONES Visite www.BlackandDecker.com/NewOwner para registrar su nuevo producto. L L E E A A E E L L M M A A N N U U A A L L A A N N T T E E S S D D E E D D E E V V O O L L V V E E R R E E S S T T E E P P R R O O D D U U C C T T O O Si tiene una consulta o algún inconveniente con su producto Black &...
  • Page 24: Lea Todas Las Instrucciones

    NORMAS DE SEGURIDAD: DEFINICIONES Es importante que lea y comprenda este manual. La información que contiene está relacionada con la protección de SU SEGURIDAD y la PREVENCIÓN DE PROBLEMAS. Los símbolos que siguen se utilizan para ayudarlo a reconocer esta información. PELIGRO: Indica una situación de peligro inminente que, si no se evita, provocará...
  • Page 25: Funcionamiento En Pendiente

    a vibrar de manera anormal, suelte de inmediato el estribo de suspensión, espere que la hoja se detenga, retire la llave de seguridad y examine la máquina para detectar la causa de esa vibración. La vibración por lo general es una advertencia acerca de la existencia de un problema.
  • Page 26 PELIGRO: ADVERTENCIAS ADICIONALES PARA PODADORAS • Cuando opere la podadora, agarre SIEMPRE con firmeza el mango con ambas manos. • NUNCA escuche radio o use auriculares para escuchar música cuando opere la podadora. • RECOJA el cabello largo. • NUNCA intente realizar un ajuste de la altura de las ruedas con el motor en funcionamiento o con la llave de seguridad colocada en su alojamiento.
  • Page 27: Operación

    podadora cuando la temperatura está por encima de 40 °C (104 °F) o por debajo de 5 °C (41 °F). 6. Mantenga la podadora y el cargador lejos del agua, fuentes de calor (como radiadores, calefactores, estufas, etc.), el fuego o agentes químicos.
  • Page 28: Mantenimiento

    CÓMO INSTALAR LA PIEZA PARA MANTILLO 1. Repita los pasos 1 y 2 indicados para retirar la pieza. 2. Ahora deslice la pieza I-3 en la abertura de descarga hasta que se asiente en firme con la plataforma. 3. Suelte la puerta trasera y verifique que cierre correctamente. CÓMO INSTALAR EL RECOLECTOR DE CÉSPED 1.
  • Page 29 2. Corte un trozo de madera N-1de 2 x 4 [aproximadamente 61 cm (2 pies.) de largo], este se utilizará para impedir que la hoja rote cuando se extraiga la tuerca con brida. 3. Voltee la podadora sobre uno de los lados. Utilice guantes y protección ocular adecuada.
  • Page 30 Accesorios Los accesorios recomendados para usar con la podadora están disponibles en su distribuidor local o centro de mantenimiento autorizado. Si necesita asistencia en relación con los accesorios, llame al: 1-800-544-6986 ADVERTENCIA: El uso de accesorios no recomendados para utilizar con esta herramienta puede resultar peligroso. p/n 242354-01 INSERTO PARA DESBROZAR p/n 242867-00 CONDUCTO DE DESCARGA...
  • Page 31: Guía De Solución De Problemas

    GUÍA DE SOLUCIÓN DE PROBLEMAS PROBLEMA La podadora no funciona cuando se acciona el estribo de suspensión. El motor se detiene mientras está cortando el césped. La podadora funciona, pero el rendimiento de corte no es satisfactorio o no corta el césped en su totalidad.
  • Page 32 BOSQUES DE CIDROS ACCESO RADIATAS NO. 42 COL. BOSQUES DE LAS LOMAS. 05120 MÉXICO, D.F TEL. 55-5326-7100 Cat No. CMM1200 Copyright © 2008 Black & Decker SECCI N AMARILLA Si funciona… y funciona muy bien. Form No. 90541667 OCT. ‘08 Printed in Mexico...
