Imperial Oban Marble Installation Instructions

INSTRUCT29

REV120111 B/MM

General Installation Instructions for Oban Basin Stands

Important Information:

Please check the products for transport damage and that contents are complete

before installation.

Consult a qualified plumber if you have any problems installing this product.

Complaints made following installation regarding the above cannot be accepted.

Table of Contents

Do you have a question about the Oban Marble and is the answer not in the manual?

Page 1 INSTRUCT29 REV120111 B/MM General Installation Instructions for Oban Basin Stands Important Information: Please check the products for transport damage and that contents are complete before installation. Consult a qualified plumber if you have any problems installing this product. Complaints made following installation regarding the above cannot be accepted.
Page 2 Installation Guide - Introduction Thank you for purchasing this imperial product. These instructions relate to the following products. Oban Marble Console Oban Basin Stand Before you start: Check you have the necessary tools for the installation. It is advisable to prepare a clear area to assemble the products. Lay a soft blanket or sheet to protect the metal finish from scratches.
Page 3 Assembly Instructions 1: Fix Left Leg (a) to Side Trim (d) using Hex Head Screws (g) and Washers (h). Ensure that the top surface of the side trim is level with the top surface of the leg. Repeat this proceedure for the Right Leg. 2: Position Front Trim (c) to the Left Leg (a) and fix into place with Hex Head Screws (g) and Washers (h).
Page 4 Assembly Instructions 12: Carefully lower the basin into location and check that the product sits level. Fine adjustments can be made by rotating the adjustor sections of the side trims. Once you are fully happy with the fit of the basin on the stand run a bead of silicon along the back face of the basin and ensure contact with the wall is made.

Oban basin
